UDM-PRO
The UDM-PRO from Ubiquiti Networks is an all-in-one enterprise network appliance. The Ubiquiti UniFi Dream Machine Pro integrates all current and upcoming UniFi controllers with a security gateway, 10G SFP+ WAN, 8-port Gbps switch and off-the-shelf 3.5" HDD support.
UDM Pro Key Features
- All-in-one 1U rack appliance for small to medium sized businesses
- Combines new UniFi OS with 8-port switch and security gateway
- UniFi Protect video surveillance NVR with off-the-shelf 3.5" HDD support
- 8-port Gigabit Switch with 1 Gbps RJ45 and 10G SFP+ LAN
- Enterprise-class IPS/IDS, DPI, and Wi-Fi AI capabilities
- Powered by fast 1.7 GHz quad-core processor
- HDD/SSD
UDM-PRO - Ubiquiti UniFi Dream Machine Pro
Description: The UniFi Dream Machine Pro is a powerful unified enterprise network appliance. It integrates software – the UniFi Network Controller and UniFi Protect video surveillance – with all-in-one hardware featuring a high-performance security gateway with a built-in switch and hard drive bay.
Features of UDMP:
- 8-Port gigabit switch with 10G SFP+ port
- Dual WAN ports for redundancy and load balancing: 10G SFP+ and 1G RJ-45
- Bluetooth connectivity for easy setup via UniFi app
- Scalable UniFi Network Controller with advanced management capabilities
- UniFi Protect video surveillance NVR with 3.5" (or 2.5") HDD support
- Enterprise-class IPS/IDS and DPI capabilities
- 1 x 1.3" Touchscreen display for quick status information
- Powered by fast 1.7 GHz quad-core processor
Specifications
UDM-PRO | |
---|---|
Dimensions | 442.4 x 43.7 x 285.6 mm |
Weight With Mount Brackets |
3.90 kg 3.99 kg |
Max. Power Consumption | 33W |
Power Supply | Internal 50W/12V |
Power Input | (1) Universal AC Input, 100 to 240VAC (1) RPS DC Input |
LEDs | |
Display | 1.3" Color Touch Panel |
System | Status |
HDD | Activity |
RJ45 | Link/Speed/Activity |
SFP+ | Link/Speed/Activity |
Networking Interfaces | |
Serial Console Port | None |
Data Ports | (8) 10/100/1000 RJ45 LAN Ports |
(1) 10/100/1000 RJ45 WAN Ports | |
(1) 1/10G SFP+ LAN Port | |
(1) 1/10G SFP+ WAN Port | |
(0) Power Over Ethernet Ports | |
Layer 3 Forwarding Performance | |
Packet Size: N/A | N/A |
IPS/IDS Enabled Throughput | approx 3.5 Gbps |
IPS/IDS Disabled Throughput | approx 9 Gbps |
Processor | AnnapurnaLabs Alpine AL-324 ARM® Cortex-A57 quad-core 1.7GHz processor |
System Memory | 4 GB DDR4 |
On-Board Flash Storage | 16 GB eMMC |
User Replaceable Hard Drive (not included) | (1) 3.5" or (1) 2.5" SATA 3 |
Certifications | CE, FCC, IC |
Rackmount | Yes |
Operating Temperature | -10 to 40° C (14 to 104° F) |
Operating Humidity | 5 to 95% Noncondensing |
ESD/EMP Protection | Air: ± 16 kV, Contact: ± 12 kV |
- Device Type
- Access Point
Network Switch
Router - Device Features
- Bluetooth Support
Managed
Rackmount - SFP+ Ports
- 1
- Power Input
- AC
- SFP
- Yes, 1G SFP
Yes, 10G SFP+ - Ethernet Ports
- 8 Eth ports
