Sxt 5Hnd PtP MPLS bridge

The new Nv2 (TDMA) Sxt 5HnD CPE by Mikrotik can suprise with the speed, configurability and scalability. Even though it has only Level3 of Mikrotik License it is enough to make PtP bridge. This is an example shows how the bridge be done using MPLS instead of WDS.

 Bridge:
/interface wireless
set wlan1 adaptive-noise-immunity=ap-and-client-mode band=5ghz-onlyn basic-rates-a/g=""
country=australia disabled=no frequency=5180 frequency-mode=manual-txpower
ht-ampdu-priorities=0,1,2,3,4,5,6,7 ht-extension-channel=below-control ht-rxchains=0,1
ht-txchains=0,1 mode=bridge rate-set=configured ssid=wisp.net.au supported-rates-a/g=""
wireless-protocol=nv2
/ip address
add address=172.16.0.1/30 interface=wlan1
/mpls ldp
set enabled=yes lsr-id=172.16.0.1 transport-address=172.16.0.1
/mpls ldp interface
add interface=wlan1
/interface vpls
add name=vpls1 remote-peer=172.16.0.2 vpls-id=1:1 disabled=no
/interface bridge add name=bridge1
/interface bridge port
add bridge=bridge1 interface=ether1
add bridge=bridge1 interface=vpls1
/mpls interface set 0 mpls-mtu=1522

CPE:
/interface wireless
set wlan1 adaptive-noise-immunity=ap-and-client-mode band=5ghz-onlyn basic-rates-a/g=""
country=australia disabled=no frequency=5180 frequency-mode=manual-txpower
ht-ampdu-priorities=0,1,2,3,4,5,6,7 ht-extension-channel=below-control ht-rxchains=0,1
ht-txchains=0,1 mode=station rate-set=configured ssid=wisp.net.au supported-rates-a/g=""
wireless-protocol=nv2
/ip address
add address=172.16.0.2/30 interface=wlan1
/mpls ldp
set enabled=yes lsr-id=172.16.0.2 transport-address=172.16.0.2
/mpls ldp interface
add interface=wlan1
/interface vpls
add name=vpls1 remote-peer=172.16.0.1 vpls-id=1:1 disabled=no
/interface bridge add name=bridge1
/interface bridge port
add bridge=bridge1 interface=ether1
add bridge=bridge1 interface=vpls1
/mpls interface set 0 mpls-mtu=1522


Link to the device
