Channel to Frequency Table

802.11a:
36 - 5180
40 - 5200
44 - 5220
48 - 5240
52 - 5260
56 - 5280
60 - 5300
64 - 5320
100 - 5500
104 - 5520
108 - 5540
112 - 5560
116 - 5580
120 - 5600
124 - 5620
128 - 5640
132 - 5660
136 - 5680
140 - 5700
149 - 5745
153 - 5765
157 - 5785
161 - 5805
165 - 5825		802.11b:
1 - 2412
2 - 2417
3 - 2422
4 - 2427
5 - 2432
6 - 2437
7 - 2442
8 - 2447
9 - 2452
10 - 2457
11 - 2462
12 - 2467
13 - 2472		Channel map for 900MHz in 2.4GHz frequency for GZ-901:
1 (2412) = 868
2 (2417) = 873
3 (2422) = 878
4 (2427) = 883
5 (2432) = 888
6 (2437) = 893
7 (2442) = 898
8 (2447) = 903
9 (2452) = 908
10 (2457) = 913
11 (2462) = 918
12 (2467) = 923
13 (2472) = 928		Channel mapping for 2.4GHz for SR9:
3 (2422) 922 MHz
4 (2427) 917 MHz
5 (2432) 912 MHz
6 (2437) 907 MHz
