ASRock Rack 1U10E-ALTRA/1L2T 1U Ampere Altra Server with 10x NVMe Dual 10GbE IPMI and Redundant 650W Platinum PSU

1U10E-ALTRA/1L2T
ETA end of August
$4,034.80
Tax included

1U10E-ALTRA/1L2T

  • 1U Rackmount with 1+1, 80-PLUS Platinum, 650W Slim PSU
  • Single Socket (LGA 4926), supports Ampere Altra Max/Ampere Altra processors
  • 8 DIMM slots (1DPC), supports DDR4 288-pin RDIMM, LRDIMM
  • 10 Hot-swap NVMe (PCIe4.0 x4) drive bays
  • 1 FHFL single-slot PCIe4.0 x16
  • Supports 2 M.2 (PCIe4.0 x4)
  • 2 RJ45 (10GbE) by Intel X550
  • 1 RJ45 (1GbE) by Intel® i210
  • Remote management (IPMI)

Related Products & Accessories



1U10E-ALTRA/1L2T 1U ASRock Rack Ampere Altra Server with 10x NVMe, Dual 10GbE, IPMI, and Redundant 650W Platinum PSU

Specifications

System
Form Factor 1U Rackmount
Dimensions 625.0 x 430.0 x 43.5 mm (24.6'' x 16.9'' x 1.7'')
Support MB ALTRAD8UD-1L2T
Front Panel
Buttons Power, System reset button
LEDs LAN Activity, HDD Activity, Power
I/O Ports 1 Type-A (USB3.2 Gen1)
External Drive Bay / Storage
Front Side Drive Bay 10 Hot-swap NVMe (PCIe4.0 x4) drive bays
Front Side Backplane 10-port NVMe passive backplane (1U10E-BPB_G4)
Internal Side 2 M-key (PCIe4.0 x4); support 2280/2230 form factor
Power Supply
Type 1+1 Slim PSU
Output Watts 650W @ 100-240Vac input
Efficiency 80-PLUS Platinum
AC Input AC 100-240V/9A, 50-60Hz
System Fan
Fan 5 PWM easy-swap 40x56 mm fans
Processor System
CPU Supports Ampere Altra Max/Ampere Altra processors
Socket Single Socket (LGA 4926)
Chipset System on Chip
System Memory
Supported DIMM Quantity 8 DIMM slots (1DPC)
Supported Type Supports DDR4 288-pin RDIMM, LRDIMM
Max. Capacity per DIMM 256GB
Max. DIMM Frequency 3200 MHz
Voltage 1.2V
PCIe Expansion Slots
PCIe x16 1 FHFL single-slot PCIe4.0 x16* via RB1UX16_G4
*Supports PCIe4.0 x8 when using Ampere Altra processors
Ethernet
Additional GbE Controller Intel® X550: 2 RJ45 (10GbE)
Intel® i210: 1 RJ45 (1GbE)
Server Management
BMC Controller ASPEED AST2500
IPMI Dedicated GLAN 1 Realtek RTL8211E for dedicated management GLAN
Graphics
Controller ASPEED AST2500
VRAM DDR4 512MB
Rear I/O
UID Button/LED 1 UID button w/ LED
Video Port 1 DB15 (VGA)
USB 3.2 Gen1 Port 4 Type-A (USB3.2 Gen1)
RJ45 2 RJ45 (10GbE)
1 RJ45 (1GbE)
1 dedicated IPMI
System BIOS
BIOS Type AMI UEFI BIOS; 256 Mb (32MB) SPI Flash ROM
BIOS Features ASRock Rack Instant Flash, ACPI 6.2, SMBIOS 3.4.0 and above, Plug and Play (PnP)
Hardware Monitor
Temperature SOC, MB Temperature sensing
Fan Fan Tachometer, CPU Quiet Fan, Fan Multi-Speed Control
Voltage 12V, 5V, 3V3, 5VSB, 0V8_VDDC_SOC, BAT, 0V75_PCP_CPU, 1V8_PCP, 1V2_VDDQ0123, 1V2_VDDQ4567, 0V6_VTT0123, 0V6_VTT4567, 3V3_SOC, 1V8_VDDH, 1V5_VDDH, 0V85_VDDC_RCA
Supported OS
OS RHEL 8.5 aarch64
RHEL 9.2 aarch64
CentOS-Stream 8 aarch64
CentOS-Stream 9 aarch64
Environment
Temperature Operation: 10°C ~ 35°C
Non-operation: -40°C ~ 70°C
Humidity Non-operation: 20% ~ 90% (Non-condensing)
Device Features
Rackmount
I/O Ports
2 Type-A (USB3.2 Gen1)
