Ubiquiti UniFi UA-Ultra Access Ultra All-in-One PoE+ Door Access Reader & Hub

UA-Ultra
Last items in stock
$206.68
Tax included

Access Ultra, UA-Ultra

An access reader with a built-in hub for complete, single-door entry control from one device.

Key Features:

  • (1) Lock terminal (12V DC, 1A)
  • (1) Exit request input
  • Unlock using an NFC card or UniFi Identity mobile app
  • Connect and power using PoE+
  • IP55-rated weather resistance (-30 to 40° C)

    Note. Not compatible with standalone Access Hubs.

Related Products & Accessories



Access Ultra, UA-Ultra

The Ubiquiti Access Ultra (UA-Ultra) is an advanced, all-in-one access control reader with a built-in hub, designed for seamless single-door entry management. Featuring a lock terminal (12V DC, 1A) and exit request input, it allows complete control from a single device, reducing wiring complexity. Users can unlock doors using NFC cards or the UniFi Identity mobile app, ensuring secure and convenient access. Powered via PoE+, it simplifies installation while integrating effortlessly into the UniFi Access ecosystem for centralized management. With an IP55-rated weather-resistant design and an operating range of -30 to 40°C, the UA-Ultra is a durable and versatile solution for modern security needs.

Technical Specification

Mechanical
Dimensions 126 x 45 x 37.45 mm (4.9 x 1.8 x 4.5")
Weight 140 g (4.9 oz)
Enclosure material Polycarbonate, aluminum alloy
Mounting Wall mount, gang box mount
Weatherproofing IP55
Hardware
Networking interface 10/100 MbE RJ45 port
Connectivity Ethernet
BLE 4.2
Digital input (1) Exit request
Lock terminals (1) 12V DC, 1A
Power method PoE+
UL 294 Power-limited Class 2 PSU
UL 60950-1/62368-1 LPS/PS2 PSU
Supported voltage range 44–57V DC
Max. power consumption 18W
ESD/EMP protection Air: ±8kV, contact: ± 4kV
LEDs R/G/B/W
Button (1) Factory reset
Tamper switch Yes
Speaker Buzzer
NFC frequency 13.56 Mhz
NFC read range < 50 mm
NFC standards ISO 14443A, 14443B, 15693
NFC technology NFC Tag 1,2,3,4,5
MIFARE Classic
MIFARE Plus
Mifare Ultralight
MIFARE DESFire
Operating environment Outdoor use
Ambient operating temperature -30 to 40° C (-22 to 104° F)
Ambient operating humidity 5 to 90% noncondensing
UL 294 statement Compliance with IEEE 802.3 specifications was not verified as part of UL 294.
The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits.
PoE cabling requirements Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site.
The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm 2 ) for patch cords; 24 AWG (0.21 mm 2 ) for horizontal or riser cable.
CAN/ULC-60839-11-1 Grade Grade assignment: I
Certifications CE, FCC, IC, UL 294, CAN/ULC-60839-11-1
Document number, and issue date and/or revision level UA-Ultra, V01

Device Features
Outdoor
POE Ports
1 port 10/100 Mbps
Operating Temperature
-30 to 40° C (-22 to 104° F)
Networking Interface
10/100 MbE RJ45 port
0810084694305
UA-Ultra
