PLANET IGS-6325-8T8S4X Industrial 20-Port 1G SFP + 4-Port TP/SFP + 4-Port 10G SFP+ Managed Gigabit Switch

PLANET Industrial 20-Port 1G SFP + 4-Port TP/SFP + 4-Port 10G SFP+ Managed Gigabit Switch

IGS-6325-8T8S4X
Available On Backorder
$1,303.49
Tax included

PLANET IGS-6325-20S4C4X Industrial Layer 3 Managed Switch features 20 100/1000Mbps SFP ports, 4 shared SFP ports, 4 10G SFP+ ports and Layer 3 IP routing in a 1U case. With 10Gbps uplink, the IGS-6325-20S4C4X can handle extremely large amounts of data in a secure topology linking to an industrial backbone or high capacity servers. The IGS-6325-20S4C4X is capable of providing non-blocking switch fabric and wire-speed throughput as high as 128Gbps in the temperature range from -40 to 75 degrees C. It greatly simplifies the tasks of upgrading the industrial LAN for catering to increasing bandwidth demands. Furthermore, it adopts user-friendly “Front Access” design for easy wiring and maintenance of the IGS-6325-20S4C4X when placed in the cabinet.

The IGS-6325-20S4C4X possesses a 100~240V AC power supply and dual 36~60V DC power supply utilized as redundant power supply to ensure its continuous operation. Its redundant power system is specifically designed to handle the demands of high-tech facilities requiring the highest power integrity. Furthermore, with the 36~60V DC power supply implemented, the IGS-6325-20S4C4X can be applied as the telecom level device and placed in almost any difficult environment.

Physical Port

  • 20 100/1000BASE-X mini-GBIC/SFP slots
  • 4 10/100/1000BASE-T RJ45 ports, shared with Port-1 to Port-4
  • 4 10GBASE-SR/LR SFP+ slots, compatible with 1000BASE-SX/LX/BX SFP
  • RJ45 to RS232 console interface for basic management and setup

Hardware Conformance

  • One 100 to 240V AC or dual 36 to 60V DC power input, redundant power with polarity reverse protect function
  • - Active-active redundant power failure protection
    - Backup of catastrophic power failure on one supply
    - Fault tolerance and resilience
  • 19-inch rack-mountable design
  • IP30 metal case
  • Supports EFT 6000V DC protection and 6000V DC Ethernet ESD protection
  • -40 to 75 degrees C operating temperature for DC power input
  • -10 to 60 degrees C operating temperature for AC power input

Layer 3 IP Routing Features

  • Supports maximum 128 static routes and route summarization
  • IP dynamic routing protocol supports OSPFv2
  • Routing interface provides per VLAN routing mode
Device Features
Rackmount, Managed, Industrial
SFP+ Ports
4
Power Input
DC, AC
Device Type
Network Switch
SFP Ports
24
SFP
Yes, 10G SFP+, Yes, 1G SFP
Ethernet Ports
4
Environment Temperature
-40℃~75℃
No reviews

Hardware Specifications
Copper Ports 4 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports, shared with Port-1 to Port-4
SFP/mini-GBIC Slots 24 100/1000BASE-X SFP interfaces,
Compatible with 100BASE-FX SFP transceiver
SFP+ Slots 4 10GbBASE-SR/LR SFP+ interfaces (Port-25 to Port-28)
Compatible with 1000BASE-SX/LX/BX SFP transceiver
Console 1 x RS232-to-RJ45 serial port (115200, 8, N, 1)
Switch Architecture Store-and-Forward
Switch Fabric 128Gbps/non-blocking
Throughput 95.2Mpps@64Bytes
Address Table 16K entries, automatic source address learning and aging
Shared Data Buffer 32M bits
Flow Control IEEE 802.3x pause frame for full duplex
Back pressure for half duplex
Jumbo Frame 10K bytes
Reset Button < 5 sec: System reboot
> 5 sec: Factory default
Dimensions (W x D x H) 440 x 200 x 44.5 mm, 1U height
Weight 2.935kg
LED Indicator System:
 AC (Green), DC1 (Green), DC2 (Green), Fault (Red)
 Ring (Green), DI/DO. (Green)
10/100/1000T RJ45 Interfaces (Port 1 to Port 4):
 1000Mbps LNK/ACT (Green)
 10/100Mbps LNK/ACT (Amber)
100/1000Mbps SFP Combo Interfaces (Port 21 to Port 24):
 1000Mbps LNK/ACT (Green)
 100Mbps LNK/ACT (Amber)
1/10Gbps SFP+ Interfaces (Port 25 to Port 28):
 10Gbps LNK/ACT (Amber)
 1Gbps LNK/ACT (Green)
Power Consumption AC input:
Max. 38.3 watts/131.4 BTU
DC input:
Max. 41.4 watts/142 BTU
Power Requirements – AC AC 100~240V, 50/60Hz 1A
Power Requirements – DC DC 36~60V, 1.5A
DI and DO 2 digital input (DI):
Level 0: -24~2.1V
Level 1: 2.1~24V
Max. input current: 10mA
2 digital output (DO): Open collector to 24VDC, 100mA
EFT Protection 6KV DC
ESD Protection 6KV DC
Layer 2 Management Functions
Port Configuration Port disable/enable
Auto-negotiation 10/100/1000Mbps full and half duplex mode selection
Flow control disable/enable
Port Status Display each port’s speed duplex mode, link status, flow control status, auto-negotiation status, trunk status
Port Mirroring TX/RX/Both
Many-to-1 monitor
VLAN 802.1Q tagged VLAN
Q-in-Q tunneling
Private VLAN Edge (PVE)
MAC-based VLAN
Protocol-based VLAN
Voice VLAN
IP Subnet-based VLAN
MVR (Multicast VLAN registration)
Up to 256 VLAN groups, out of 4096 VLAN IDs
GVRP
Link Aggregation IEEE 802.3ad LACP/static trunk
14 trunk groups with 16 port per trunk group
Spanning Tree Protocol IEEE 802.1D Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree Protocol
IEEE 802.1s Multiple Spanning Tree Protocol
QoS Traffic classification based, strict priority and WRR
8-level priority for switching:
 - Port number
 - 802.1p priority
 - 802.1Q VLAN tag
 - DSCP/ToS field in IP packet
IGMP Snooping IGMP (v1/v2/v3) snooping, up to 255 multicast groups
IGMP querier mode support
MLD Snooping MLD (v1/v2) snooping, up to 255 multicast groups
MLD querier mode support
Access Control List IP-based ACL/MAC-based ACL
Up to 256 entries
Bandwidth Control Per port bandwidth control
Ingress: 100Kbps~1000Mbps
Egress: 100Kbps~1000Mbps
Layer 3 Functions
IP Interfaces Max. 128 VLAN interfaces
Routing Table Max. 128 routing entries
Routing Protocols IPv4 hardware static routing
IPv6 hardware static routing
OSPFv2 dynamic routing
Management
Basic Management Interfaces Console; Telnet; Web browser; SNMP v1, v2c
Secure Management Interfaces SSH, SSL, SNMPv3
SNMP MIBs RFC 1213 MIB-II
RFC 1493 Bridge MIB
RFC 1643 Ethernet MIB
RFC 2863 Interface MIB
RFC 2665 Ether-Like MIB
RFC 2819 RMON MIB (Group 1, 2, 3 and 9)
RFC 2737 Entity MIB
RFC 2618 RADIUS Client MIB
RFC 2863 IF-MIB
RFC 2933 IGMP-STD-MIB
RFC 3411 SNMP-Frameworks-MIB
RFC 4292 IP Forward MIB
RFC 4293 IP MIB
RFC 4836 MAU-MIB
IEEE 802.1X PAE
LLDP
Standards Conformance
Regulatory Compliance FCC Part 15 Class A, CE
Standards Compliance IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX/100BASE-FX
IEEE 802.3z Gigabit SX/LX
IEEE 802.3ab Gigabit 1000T
IEEE 802.3ae 10Gb/s Ethernet
IEEE 802.3x flow control and back pressure
IEEE 802.3ad port trunk with LACP
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree Protocol
IEEE 802.1s Multiple Spanning Tree Protocol
IEEE 802.1p Class of Service
IEEE 802.1Q VLAN tagging
IEEE 802.1X Port Authentication Network Control
IEEE 802.1ab LLDP
IEEE 802.3ah OAM
IEEE 802.1ag Connectivity Fault Management(CFM)
RFC 768 UDP
RFC 793 TFTP
RFC 791 IP
RFC 792 ICMP
RFC 2068 HTTP
RFC 1112 IGMP v1
RFC 2236 IGMP v2
RFC 2328 OSPF v2
RFC 3376 IGMP v3
RFC 2710 MLD v1
FRC 3810 MLD v2
ITU G.8032 Ethernet Ring Protection Switching
ITU-T G.8032 ERPS Ring
ITU-T Y.1731 Performance Monitoring
Environment
Operating Temperature: -10 ~ 60 degrees C for AC power input
       -40 ~ 75 degrees C for DC power input
Relative Humidity: 5 ~ 95% (non-condensing)
Storage Temperature: -40 ~ 80 degrees C
Relative Humidity: 5 ~ 95% (non-condensing)
