PWR-480-48 Industrial 48V 480W DIN Rail Power Supply

    PWR-480-48 Industrial 48V 480W DIN Rail Power Supply

    PWR-480-48
    Last items in stock
    A$190.00
    Tax included

    Compact Size with more Practicability and Convenience
    PLANET has released a series of DC single output industrial DIN rail power supply units to make sure that industrial Ethernet devices, specially designed for the harsh working environment, get DC voltage power easily.
    PLANET DC single output industrial DIN rail power supply units accept universal 100-240V AC input voltage and provide 48V DC power output with various watt values. Its power supply units are designed in compact size and can be installed on DIN rail TS-35 / 7.5 or 15. It is an ideal and convenient DC power feeding solution for Industrial equipment under heavy Industrial environments.

    Stable Performance under Difficult Environments
    PLANET DC single output industrial DIN rail power supply units come with such protection features as short circuit, overload, over voltage and over temperature for the stable operation of industrial Ethernet equipment. It uses the free air convection cooling system to prevent operating temperature from rising. Being able to operate under the temperature range from -20 to 70 degrees C (maximum), the DC single output industrial DIN rail power supply units can be placed in almost any difficult environments.

    QuantityPriceYou Save
    10A$181.00Up to A$90.00

    Compact Size with more Practicability and Convenience
    PLANET has released a series of DC single output industrial DIN rail power supply units to make sure that industrial Ethernet devices, specially designed for the harsh working environment, get DC voltage power easily.
    PLANET DC single output industrial DIN rail power supply units accept universal 100-240V AC input voltage and provide 48V DC power output with various watt values. Its power supply units are designed in compact size and can be installed on DIN rail TS-35 / 7.5 or 15. It is an ideal and convenient DC power feeding solution for Industrial equipment under heavy Industrial environments.

    Stable Performance under Difficult Environments
    PLANET DC single output industrial DIN rail power supply units come with such protection features as short circuit, overload, over voltage and over temperature for the stable operation of industrial Ethernet equipment. It uses the free air convection cooling system to prevent operating temperature from rising. Being able to operate under the temperature range from -20 to 70 degrees C (maximum), the DC single output industrial DIN rail power supply units can be placed in almost any difficult environments.

    Ideal 48V DC Power Feeding Solution for PoE Industrial Equipment

    The following DC single output industrial DIN rail power supply units provide sufficient 48V power to Industrial PoE equipment, such as industrial PoE Ethernet switches and industrial PoE wireless access points.

    PWR-480-48 (MEAN WELL/NDR-480-48) Features:

    • Universal AC input full operation
    • Built-in active PFC function
    • Protection features: short circuit, overload, over voltage and over temperature
    • Cooling by free air convection
    • DIN rail TS-35/7.5 or 15 installation
    • UL 508 (industrial control equipment) approved
    • EN61000-6-2 (EN50082-2) industrial immunity leve
    • 100% full load burn-in tes

    Specifications

    PWR-480-48 (MEAN WELL/NDR-480-48)
    Hardware Version2
    Dimensions (W x D x H)85 x 125 x 128mm
    Weight (kg)1.5kg
    Input Voltage100-240V AC,50/60Hz, 4.8A
    Power Output480 watts, 48V, 10A
    TemperatureOperating:-20~70 degrees C (**)
    Storage:-40~85 degrees C
    HumidityOperating: 20 ~ 95%
    Storage: 10 ~ 95% (non-condensing)
    InstallationDIN rail TS-35/7.5 or 15
    Safety & FunctionUl508, TUV EN60950-1 approved (meeting EN60204-1)
    *Note*The specification is for PWR-480-48 hardware version 2 only.
    **Please refer to output load derating curve from product specification.
