Ubiquiti UniFi U7-Pro-Max
Ubiquiti UniFi U7-Pro-Max | Buy Ubiquiti UniFi U7-Pro-Max WiFi 7 High Capacity Indoor AP, 8 spatial streams, 6 GHz support|Wisp
Ubiquiti UniFi U7-Pro-Max | Buy Ubiquiti UniFi U7-Pro-Max WiFi 7 High Capacity Indoor AP, 8 spatial streams, 6 GHz support|Wisp
Ubiquiti UniFi U7-Pro-Max | Buy Ubiquiti UniFi U7-Pro-Max WiFi 7 High Capacity Indoor AP, 8 spatial streams, 6 GHz support|Wisp

Ubiquiti UniFi U7-Pro-Max WiFi 7 High Capacity Indoor Access Point, 8 spatial streams, 6 GHz support

U7-Pro-Max
Last items in stock
$528.00
Tax included

U7-Pro-Max

Ceiling-mounted WiFi 7 AP with 8 spatial streams, 6 GHz support, and a dedicated spectral scanning engine for interference-free WiFi in demanding, large-scale environments.

Features:

  •  WiFi 7 with 6 GHz support
  •  8 spatial streams
  •  Real-time spectral analysis for enhanced channel selection*
  •  160 m² (1,750 ft²) coverage
  •  500+ connected devices
  •  Powered using PoE+
  •  2.5 GbE uplink
  • PoE adapter (not included)



U7-Pro-Max

Technical Specifications

Mechanical
Dimensions Ø206 x 46 mm (Ø8.1 x 1.8")
Weight 680 g (1.5 lb)
Enclosure material Polycarbonate, aluminum
Mount material Stainless steel (SUS304), galvanized steel (SGCC)
Hardware
Networking interface (1) 1/2.5 GbE RJ45 port
Management interface Ethernet
Power method PoE+
Power supply UniFi PoE switch
Supported voltage range 44—57V DC
Max. power consumption 25W
Max. TX power
2.4 GHz
5 GHz
6 GHz

23 dBm
29 dBm
23 dBm
MIMO
2.4 GHz
5 GHz
6 GHz

2 x 2 (DL/UL MU-MIMO)
4 x 4 (DL/UL MU-MIMO)
2 x 2 (DL/UL MU-MIMO)
Max. data rate
2.4 GHz
5 GHz
6 GHz

688 Mbps (BW40)
8.6 Gbps (BW240)
5.7 Gbps (BW320)
Antenna gain
2.4 GHz
5 GHz
6 GHz

4 dBi
6 dBi
5.9 dBi
LEDs White/blue
Button Factory reset
Mounting Wall, ceiling (Included)
Ambient operating temperature -30 to 50° C (-22 to 122° F)
Ambient operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
Software
WiFi standards 802.11a/b/g/n/ac/ax/be (WiFi 6/6E, WiFi 7)
Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
BSSID 8 per radio
VLAN 802.1Q
Advanced QoS Per-user rate limiting
Guest traffic isolation Supported
Concurrent clients 500+
Supported Data Rates
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40)
802.11ac 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
802.11ax (WiFi 6/6E) 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
802.11be (WiFi 7)
5 GHz
6 GHz

7.3 Mbps to 8.6 Gbps (MCS0 - MCS13 NSS1/2/3/4, EHT 20/40/80/160/240)
7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320)
Application Requirements
UniFi Network Version 8.2.93 and later

Antenna Gain (dBi)
4
5.9
6
Device Type
Access Point
MIMO
2x2
4x4
Wireless System
2.4GHz
5GHz
6GHz
Wi-Fi 7
Ethernet Ports
1 Eth port
810084695555
U7-Pro-max
