GWN7664E
*** Out of stock ATM, Available On Backorder ***
$305.00
Tax included

GWN7664E

The GWN7664E is a powerful, enterprise-grade 802.11ax Wi-Fi 6 access point, ideal for medium-to-large sized businesses, multiple-floor buildings, residential settings, and commercial locations

features:

  • 6Gbps aggregate wireless throughput, 5Gbps aggregate wired throughput
  • Dual-band 4x4:4 MU-MIMO with DL/UL OFDMA technology
  • Up to 175-meter coverage range
  • Supports 512 concurrent Wi-Fi client devices
  • Includes 2x 2.5G Ports
  • Advanced QoS to ensure real-time performance of low-latency applications
  • Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
  • Self power adaptation upon auto detection of PoE or PoE+
  • Embedded controller manages up to 50 local GWN APs; GDMS Networking offers unlimited AP management, & GWN Manager offers on-premise software AP management

Related Products & Accessories



GWN7664E High-Performance AX6000 Wi-Fi 6 Access Point

the GWN7664E is a powerful, enterprise-grade high-performance 802.11ax Wi-Fi 6 access point, ideal for small-to- medium sized businesses, multiple floor buildings, residential settings and commercial locations. It offers dual-band 4x4:4 MU-MIMO with OFDMA technology and a sophisticated internal antenna design for stronger anti-interference, more stable connection, maximum network throughput of upto 6Gbps and expanded Wi-Fi coverage range. The GWN7664E is supported by GWN.Cloud and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management platform that makes managing your network or several networks across multiple locations easier than ever before. It also uses a controller-less network management architecture in which the controller is embedded within the product’s web user interface for easy administration of locally deployed Wi-Fi APs. The GWN7664E is the ideal Wi-Fi AP for voice-over-Wi-Fi deployments and offers a seamless connection with Grandstream’s Wi-Fi capable IP phones. With support for advanced QoS, low-latency real-time applications, mesh networks, captive portals, 512 concurrent clients and dual 2.5 Gigabit network ports with PoE+, the GWN7664E is an ideal Wi-Fi access point for business-grade wireless network deployments with medium-to-high user density.

Specifications

Wi-Fi Standards IEEE 802.11 a/b/g/n/ac/ax
Antennas 8 individual internal antennas, 4 per band
2.4GHz, gain 3.5dBi
5 GHz, gain 4.5dBi
Wi-Fi Data Rates 5G:
IEEE 802.11ax: 7.3 Mbps to 4804 Mbps
IEEE 802.11ac: 6.5 Mbps to 3467 Mbps
IEEE 802.11n: 6.5Mbps to 600Mbps
IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
2.4G:
IEEE 802.11ax: 7.3 Mbps to 1147 Mbps
IEEE 802.11n: 6.5Mbps to 600Mbps
IEEE 802.11b: 1, 2, 5.5, 11 Mbps
IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
*Actual throughput may vary depending on many factors including environmental conditions, distance between devices, radio interference in the operating environment and mix of devices in the network
Frequency Bands 2.4GHz Radio: 2400 - 2483.5 MHz
5GHz Radio: 5150 - 5895 MHz
*Not all frequency bands can be used in all regions
Channel Bandwidth 2.4G: 20 and 40 MHz
5G: 20, 40, 80 and 160 MHz
Wi-Fi and System Security WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical data/control
lockdown via digital signatures, unique security certificate and random default password per device
MU-MIMO 4×4:4 2.4GHz
4×4:4 5GHz
Coverage Range Up to 175 meters
*coverage range can vary based on environment
Maximum TX Power 5G: 25.5dBm
2.4G: 26.5dBm
*Maximum power varies by country, frequency band and MCS rate
Receiver Sensitivity 2.4G
802.11b: -97dBm@1Mbps, -89dBm@11Mbps;
802.11g: -93dBm @6Mbps, -75dBm@54Mbps;
802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz:-70dBm @MCS7;
802.11ax 20MHz: -64dBm @ MCS11; 802.11ax 40MHz: -63dBm @MCS11
5G
802.11a: -93dBm @6Mbps, -75dBm @54Mbps;
802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz:-70dBm @MCS7
802.11ac 20MHz: -70dBm@MCS8; 802.11ac: HT40:- 66dBm @MCS9; 802.11ac 80MHz: -62dBm @MCS9;
802.11ax 20MHz: -64dBm @ MCS11; 802.11ax 40MHz: -61dBm @MCS11;802.11ax 80MHz: -58dBm @MCS11;
802.11ax 160MHz:-55dBm @MCS11;
SSIDs 32 SSIDs total, 16 per radio (2.4GHz & 5GHz)
Concurrent Clients 512
Network Interfaces 2 x 2.5G Ports
Auxiliary Ports 1x Reset Pinhole, 1x Kensington lock
Mounting Indoor wall mount or ceiling mount, kits included
LEDs 3 tri-color LEDs for device tracking and status indication
Network Protocols IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM
QoS 802.11e/WMM, VLAN, TOS
Network Management Embedded controller can manage up to 50 local GWN APs
GWN.Cloud offers a free cloud management platform for unlimited GWN APs
GWN Manager offers premise-based software controller for up to 3,000 GWN APs
Power and Green Energy Efficiency PoE 802.3at;
Maximum Power Consumption: 21W
Environmental Operation: 0°Cto 50°C
Storage: -10°C to 60°C
Humidity: 10% to 95% Non-condensing
Physical Unit Dimension: 205.3mmx205.3mmx45.9mm; Unit Weight: 0.714Kg
Entire Package Dimension: 258mmx247mmx86mm; Entire Package Weight: 1.06Kg
Package Content GWN7664E 802.11ax Wireless AP, Mounting Kits, Quick Start Guide
Compliance FCC, CE, RCM, IC
Device Type
Access Point
MIMO
4x4
Wireless System
2.4GHz
5GHz
Wi-Fi 6
Ethernet Ports
2
6947273705178
GWN7664E
