Grandstream GWN7710R 6-Port Outdoor L2 Lite Managed Switch

GWN7710R
Last items in stock
$149.00
Tax included

GWN7710R

The GWN7710R is a 6-Port (5GE+1SFP) outdoor lite managed PoE switch that features an IP66-rated waterproof and dustproof casing to protect against harsh weather conditions, including rain, snow, and high temperatures.

features:

  • 5 Gigabit RJ45 ports (4 PoE output ports, 1 PoE input port)
  • IEEE 802.3 at/af or 24V/48V DC passive PoE out,Up to 60W on Port 1 and up to 30W on Port 2-4; Supports PoE Watchdog function
  • SFP Fiber Port for long-distance transmission
  • DHCP Snooping - Only allow DHCP packets from trusted ports to keep the enterprise DHCP environment safe
  • IP66 dustproof and waterproof rating; Wide operating temperature range: -40°C and 60°C
  • Supports convenient and intelligent local Web configuration, GWN Manager, and GDMS Network Management
  • STP/RSTP to guarantee fast convergence, ensure network stability, and provide link load balance and redundancy
  • Built-in QoS allows for prioritization of network traffic



GWN7710R Outdoor lite managed PoE switch

The GWN7710R is a 6-Port (5GE+1SFP) Outdoor Lite Managed PoE Switch that features an IP66-rated waterproof and dustproof casing to protect against harsh weather conditions, including rain, snow, and high temperatures. To ensure a stable and powerful network performance, the GWN7710R supports flexible and complex traffic segmentation with global or per port VLANs, provides DSCP/802.1p QoS priority management modes, bandwidth control, and storm control. It provides 4 Gigabit ports that provide passive PoE++ output, 1 Gigabit port with PoE++ input, and one 2.5G SFP port. The GWN7710R can be managed in a vareity of ways, including locally through web user interface, through the cloud with GDMS, and on-premises with GWN Manager. This outdoor lite managed switch supports pole, DIN-rail, and wall-mounted installation to support a variety of outdoor and indoor applications. With the GWN7710R, users can build scalabale, secure, high-performance, and easy-to-manage business networks for outdoor locations, hotels,restaurants, parks, campuses, public areas, and more.

Specifications

Network Protocol IPv4, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
Communication Ports
  • 5x Gigabit Ethernet Ports
  • 1x 1G/2.5G SFP Port
Power Supply
  • 12V-57V DC input
  • Standard PoE /PoE+/PoE ++
PoE In and PoE Out Ports
  • PoE In: Port 5;
  • PoE Out: Port 1 - Port 4
PoE Output
  • Standard PoE output Mode (Default)
  • Passive 24VDC or 48VDC output Mode (Configured via UI)
PoE Output Power Budget
  • Powered by Standard PoE In (802.3af/at/bt):
802.3af input: 3W output budget
802.3at input: 15W output budget
802.3bt input: 60W output budget
  • Powered by DC In (12V~57V):

DC In>12V: 60W output budget
DC In>24V: 72W output budget
DC In>36V: 100W output budget


Note: When using the DC input, the budget of PoE output depends on the external DC input power.

Max Output Power Per Port
  • Standard PoE output Mode:
Port 1 - Port 4 up to 30W on each PoE port;
  • Passive PoE output Mode:
Port 1: 4-pair 48V DC up to 60W or 4-pair 24V DC up to 30W
Port 2 - Port 4: 2-pair 48V DC up to 30W or 2-pair 24V DC up to 15W
* Note:
  • 4-Pair: Powered on pins: 1,2,4,5(+),3,6,7,8(-)
  • 2-Pair: Powered on pins: 4,5(+),7,8(-)
Auxillary Ports 1x Reset Pinhol
Forwarding Mode Store-and-forward
Total non-blocking throughput 6Gbps
SSIDs 15Gbps
Jumbo Frame 2K/3K/4K/5K/6K/7K/8K/9K/12K/15K
Forwarding Rate 11.16Mpps
Packet Buffer 4Mb
MAC 8K MAC address capacity
VLAN
  • Supports up to 32 VLANs (Out of 4K VLAN IDs)
  • port-based VLAN, 802.1Q VLAN
LAG 3
Multicast IGMP snooping, Report Message Suppression
QoS
  • Auto prioritization of the incoming port of the packet
  • Supports port priority, 802.1P priority, and DSCP priority
  • Bandwidth control
  • Rate limit
DHCP DHCP client
Maintenance Backup and restore, System reboot, Factory reset, Firmware upgrade, Support MAC address search, SNMP,
LLDP
Monitoring including port statistics, Port mirroring, Cable test, and Ping
Security
  • Storm control
  • DHCP Snooping
  • Spanning Tree
  • Loop prevention
  • PoE Watchdog
Mounting  Pole/Wall-Mount/DIN-Rail
LED Indicators
  • Per device System on : Green
  • Per Ethernet port Link/Activity: Green;
  • Per Passive PoE out port 48VDC: Orange
  • Per Passive PoE out port 24VDC: Blue
  • Support LED indicator switch
ESD ± 16kV Air, ± 16kV Contact
Environmental
  • Operating Temperature: -40 to 60 °C (-40 to 140 °F)
  • Storage Temperature: -40 to 70 °C (-40 to 158 °F)
  • Operating Humidity: Support IP66 waterproof
  • Storage Humidity: 10% to 95% Non-condensing
Dimensions (LxWxH) Unit: 210 x 150 x 52mm
Package: 466 x 286 x 258mm
Weight Unit: 0.75KG
Entire Package :1.35 KG

Package Content

1x Switch, Rack-mounting Standard Brackets , 1x QIG,4x assembled screw, 4x expansion screw ,2 x Metal
straps,1x Phoenix connector
Device Type
Network Switch
SFP Ports
1 Port
Ethernet Ports
5
GWN7710R
