PLANET Industrial 8-Port 10/100/1000T with 4-Port 30W 802.3at PoE Managed Switch

IGS-4215-4P4T
Available On Backorder
$500.49
Tax included

IGS-4215-4P4T Industrial 4-Port 10/100/1000T 802.3at PoE + 4-Port 10/100/1000T Managed Switch

Ideal, Cost-effective, Manageable PoE Solution for Hardened Environments

The IGS-4215-4P4T is a Managed Switch designed for heavy industrial demanding environments. The Industrial-grade, DIN-rail type L2/L4 Managed Gigabit PoE+ Switch features PLANET’s intelligent PoE functions to improve the availability of critical business applications.

IGS-4215-4P4T Industrial 4-Port 10/100/1000T 802.3at PoE + 4-Port 10/100/1000T Managed Switch

Ideal, Cost-effective, Manageable PoE Solution for Hardened Environments

The IGS-4215-4P4T is a Managed Switch designed for heavy industrial demanding environments. The Industrial-grade, DIN-rail type L2/L4 Managed Gigabit PoE+ Switch features PLANET’s intelligent PoE functions to improve the availability of critical business applications. The unit provides IPv6/IPv4 dual stack management and built-in L2/L4 Gigabit switching capabilities along with 4 10/100/1000BASE-T ports featuring 30-watt 802.3at PoE+ and 4 additional Gigabit copper ports. The IGS-4215-4P4T offers a quiet operation with a total power budget of up to 144 watts to support a variety of PoE applications. The unit offers operating temperature ranging from -40 to 75 degrees C in a rugged IP30 metal housing.

Built-In PoE Functions

The IGS-4215-4P4T features the following PoE management functions:

  • PD alive check
  • Scheduled power recycling
  • PoE schedule
  • PoE usage monitoring
Scheduled Power Rebooting

The IGS-4215-4P4T allows each of the connected PoE IP cameras or PoE wireless access points to reboot at a specific times each week. The unit will reduce the chance of IP camera or AP crashes resulting from buffer overflow.

Energy-Efficient Features

The IGS-4215-4P4T can effectively control the power supply besides its capability of giving high watts power. The “PoE schedule” function helps you to enable or disable PoE power feeding for each PoE port during specified time intervals and it is a powerful function to help SMBs or enterprises save power and budget. It also increases security by powering off PDs that should not be in use during non-business hours.

PoE Usage Monitoring and Intelligent LED Indicator for Real-time PoE Usage

Via the power usage chart in the web management interface, the IGS-4215-4P4T enables the administrator to monitor the status of the power usage of the connected PDs in real time. Thus, it greatly enhances the management efficiency of the facilities. Moreover, the IGS-4215-4P4T helps users to monitor the current status of PoE power usage easily and efficiently via its advanced LED indication. Called “PoE Power Usage”, the front panel of the IGS-4215-4P4T has four LED indicators of different power usages.

Environmentally Hardened Design

With the IP30 aluminum industrial case, the IGS-4215-4P4T provides a high level of immunity against electromagnetic interference and heavy electrical surges which are usually found on plant floors or in curb-side traffic control cabinets without air conditioner. The unit can operate in temperature ranges between -40 to 75 degrees C, the IGS-4215-4P4T can be placed in almost any harsh environments.

IPv6/IPv4 Dual Stack Management

The unit supports both IPv6 and IPv4 protocols and helps system integrators step in the IPv6 era without the need to replace or overhaul the IPv6 network.

Robust Layer 2 Features

The IGS-4215-4P4T can be programmed for advanced switch management functions such as dynamic port link aggregation, 802.1Q VLAN, Q-in-Q VLAN, Multiple Spanning Tree Protocol (MSTP), Loop and BPDU Guard, IGMP Snooping, and MLD Snooping. Via the link aggregation, the IGS-4215-4P4T allows the operation of a high-speed trunk to combine with multiple ports such as a 16Gbps fat pipe, and supports fail-over as well. Also, the Link Layer Discovery Protocol (LLDP) is the Layer 2 protocol included to help discover basic information about neighboring devices on the local broadcast domain.

Optimal Traffic Control

The IGS-4215-4P4T is loaded with robust QoS features and powerful traffic management to enhance services to business-class data, voice, and video solutions. The functionality includes broadcast/multicast/unicast storm control, per port bandwidth control, 802.1p/CoS/IP DSCP QoS priority and remarking. The unit guarantees the best performance in VoIP and video stream transmission allowing network administrators to efficiently manage their networking resources.

User-Friendly Management

For efficient management, the IGS-4215-4P4T is equipped with web, Telnet and SNMP management interfaces. With the built-in web-based management interface, the IGS-4215-4P4T offers an easy-to-use, platform-independent management and configuration facility. By supporting the standard SNMP, the switch can be managed via any standard management software. For text-based management, the switch can be accessed via Telnet. Moreover, the IGS-4215-4P4T offers secure remote management by supporting SSH, SSL and SNMP v3 connections which encrypt the packet content at each session.

Advanced Network Security

PLANET IGS-4215-4P4T offers a comprehensive IPv4/IPv6 Layer 2 to Layer 4 Access Control List (ACL) for enforcing security to the edge. Its protection mechanism also comprises 802.1X port-based user and device authentication, which can be deployed with RADIUS to ensure the port level security and block illegal users. With the protected port function, communication between edge ports can be prevented to guarantee user privacy. Furthermore, the IGS-4215-4P4T also provides DHCP snooping, IP source guard and dynamic ARP inspection functions to prevent IP snooping from attack and discarded ARP packets with invalid MAC address. The network administrators can now construct highly-secure corporate networks with considerably less time and effort than before.



Hardware Specifications
Copper Ports 8 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports
PoE Injector Port 4 ports with 802.3af/802.3at PoE injector function (Port-1 to Port-4)
Console 1 x RS232-to-RJ45 serial port (115200,8, N, 1)
Switch Architecture Store-and-Forward
Switch Fabric 16Gbps/non-blocking
Switch Throughput@64 bytes 11.9Mpps@64 bytes
MAC Address Table 8K entries
Shared Data Buffer 4.1 megabits
Flow Control IEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex
Jumbo Frame 10 Kbytes
Reset Button < 5 sec: System reboot
> 5 sec: Factory default
LED 3 x LED for System and Power:
â–  Green: DC Power 1
â–  Green: DC Power 2
â–  Green: Power Fault
2 x LED for PoE Copper Port (Port-1~Port-4):
â–  Green: LNK/ACT
â–  Orange: PoE-in-use
2 x LED for 10/100/1000T Copper Port (Port-5~Port-8):
â–  Green: LNK/ACT
â–  Orange: 1000Mbps
4 x LED for PoE Power Usage (W)
â–  Orange: 30, 60, 90 and 120W
Connector Removable 6-pin terminal block
Pin 1/2 for Power 1; Pin 3/4 for fault alarm; Pin 5/6 for Power 2
Alarm One relay output for power failure. Alarm relay current carry ability: 1A @ 24V AC
Power Requirements 48~56V DC, 3.5A (max.)
Power Consumption/ Dissipation 5.04 watts, 17.1BTU (Standby without PoE function)
7.28 watts, 23 BTU (Full loading without PoE function)
151.28 watts, 516.1 BTU (Full loading with PoE function)
Dimensions (W x D x H) 161 x 107 x 72 mm
Weight 1001g
ESD Protection 6KV DC
Enclosure IP30 aluminum case
Installation DIN-rail kit and wall-mount ear
Power over Ethernet
PoE Standard IEEE 802.3af/802.3at Power over Ethernet PSE
PoE Power Supply Type End-span
PoE Power Output IEEE 802.3af Standard
- Per port 48V~56V DC (depending on the power supply), max. 15.4 watts
IEEE 802.3at Standard
- Per port 50V~56V DC (depending on the power supply), max. 36 watts
Power Pin Assignment 1/2(+), 3/6(-)
PoE Power Budget 144 watts (depending on power input)
Max. Number of Class 2 PD 4
Max. Number of Class 3 PD 4
Max. Number of Class 4 PD 4
Layer 2 Functions
Port Mirroring TX/RX/Both
Many-to-1 monitor
VLAN 802.1Q tagged-based VLAN
Up to 256 VLAN groups, out of 4094 VLAN IDs
802.1ad Q-in-Q tunneling (VLAN stacking)
Voice VLAN
Protocol VLAN
Private VLAN (Protected port)
GVRP
Management VLAN
Link Aggregation IEEE 802.3ad LACP and static trunk
Supports 4 groups with 4 ports per trunk
Spanning Tree Protocol IEEE 802.1D Spanning Tree Protocol (STP)
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
STP BPDU Guard, BPDU Filtering and BPDU Forwarding
IGMP Snooping IPv4 IGMP snooping v2, v3
IGMP querier
Up to 256 multicast groups
MLD Snooping IPv6 MLD snooping v2, v3, up to 256 multicast groups
Access Control List IPv4/IPv6 IP-based ACL/MAC-based ACL
IPv4/IPv6 IP-based ACE/MAC-based ACE
QoS 8 mapping IDs to 8 level priority queues
- Port number
- 802.1p priority
- DSCP/IP precedence of IPv4/IPv6 packets
Traffic classification based, strict priority and WRR
Ingress/Egress Rate Limit per port bandwidth control
Security IEEE 802.1X port-based authentication
Built-in RADIUS client to cooperate with RADIUS server
RADIUS/TACACS+ authentication
IP-MAC port binding
MAC filtering
Static MAC address
DHCP snooping and DHCP Option82
STP BPDU guard, BPDU filtering and BPDU forwarding
DoS attack prevention
ARP inspection
IP source guard
Storm control support
- Broadcast/unknown unicast/unknown multicast
Management Functions
Basic Management Interfaces Web browser, Console, Telnet, SNMP v1, v2c, v3
Firmware upgrade by HTTP/TFTP protocol through Ethernet network
Configuration upload/download through HTTP/TFTP
Remote/local syslog
System log
LLDP protocol
SNTP
PLANET Smart Discovery Utility
Secure Management Interfaces SSH, SSL, SNMP v3
SNMP MIBs RFC 1213 MIB-II
RFC 1215 Generic Traps
RFC 1493 Bridge MIB
RFC 2674 Bridge MIB Extensions
RFC 2737 Entity MIB v2
RFC 2819 RMON (1, 2, 3, 9)
RFC 2863 Interface Group MIB
RFC 3635 Ethernet-like MIB
Standards Conformance
Regulatory Compliance FCC Part 15 Class A, CE
Stability Testing IEC 60068-2-32 (free fall)
IEC 60068-2-27 (shock)
IEC 60068-2-6 (vibration)
Standards Compliance IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3ab Gigabit 1000BASE-T
IEEE 802.3x Flow Control and Back Pressure
IEEE 802.3ad Port Trunk with LACP
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree Protocol
IEEE 802.1s Multiple Spanning Tree Protocol
IEEE 802.1p Class of Service
IEEE 802.1Q VLAN Tagging
IEEE 802.1x Port Authentication Network Control
IEEE 802.1ab LLDP
RFC 768 UDP
RFC 793 TFTP
RFC 791 IP
RFC 792 ICMP
RFC 2068 HTTP
RFC 1112 IGMP v1
RFC 2236 IGMP v2
RFC 3376 IGMP v3
RFC 2710 MLD v1
RFC 3810 MLD v2
Environment
Operating Temperature: -40 ~ 75 degrees C
Relative Humidity: 5 ~ 95% (non-condensing)
Storage Temperature: -40 ~ 85 degrees C
Relative Humidity: 5 ~ 95% (non-condensing)

Datasheet
Device Type
Network Switch, Power Over Ethernet
Device Features
Industrial, Managed
POE Ports
4
Power Input
DC
Power Over Ethernet
48V 15W 802.3af, 48V 30W 802.3at
Ethernet Ports
8
Environment Temperature
-40℃~75℃
