FMC125
Teltonika FMC125 | Buy Teltonika FMC125 Versatile 4G LTE Cat 1 tracker with RS232, RS485 interfaces|Wisp
  • New
FMC125
Teltonika FMC125 | Buy Teltonika FMC125 Versatile 4G LTE Cat 1 tracker with RS232, RS485 interfaces|Wisp

Teltonika FMC125 Versatile 4G LTE Cat 1 tracker with RS232, RS485 interfaces

FMC125
Last items in stock
$122.10
Tax included

FMC125 Advanced LTE terminal with GNSS and LTE/GSM connectivity, RS485/RS232 interfaces and backup battery

FMC125 is small and professional real-time tracking terminal with GNSS and LTE/GSM connectivity and backup battery. Device equipped with GNSS/Bluetooth and LTE modules, internal GNSS, LTE antennas. FMC125 features RS485/RS232 data interface, which gives ability to connect various third-party external devices. It is perfectly suitable for applications where location acquirement of remote objects is needed: fleet management, car rental companies, taxi companies, public transport, logistics companies, personal cars and so on.

Key features:

Fuel monitoring and more

RS232, RS485 serial interfaces for fuel monitoring and other external data reading.

Significantly lower roaming costs

Dual SIM considerably reduces roaming costs

Accurate fuel usage control

Impulse input for fuel flow meters data reading and accurate fuel usage control

Quantity Unit price You Save
5 $109.89 $61.05
10 $103.79 $183.15
20 $94.02 $561.66

Related Products & Accessories



FMC125 Advanced LTE terminal with GNSS and LTE/GSM connectivity, RS485/RS232 interfaces and backup battery

Fuel monitoring and more

RS232/RS485 serial interfaces for fuel monitoring and other external data reading

Significantly lower roaming costs

Dual SIM considerably reduces roaming costs

Accurate fuel usage control

Impulse input for fuel flow meters data reading and accurate fuel usage control
TELTONIKA DUALCAM & DASHCAM SUPPORT

Connecting via RS232 to get videos and pictures of the events that might happen on the road or inside a vehicle

PRODUCT SPECIFICATIONS

Module
Name FMC125-MBIB0: MeiG SLM320-E with Teltonika TM2500
FMC125-MCIB0: MeiG SLM320-LA with Teltonika TM2500
Technology
Technology LTE(CaT1)/2G(GSM/GPRS)/GNSS/BLUETOOTH® LE
GNSS
GNSS GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS
Receiver 33 tracking channel, 99 acquisition channel
Tracking sensitivity -165 dBM
Position Accuracy < 2.5 m CEP
Velocity Accuracy < 0.1 m/s (within +/- 15% error)
Hot start < 1 s
Warm start < 25 s
Cold start < 35 s
Cellular
Technology LTE Cat 1, GSM
2G bands FMC125-MBIB0: GSM: B2/B3/B5/B8
FMC125-MCIB0: GSM: B2/B3/B5/B8
4G LTE bands FMC125-MBIB0: LTE FDD: B1/B3/B7/B8/B20/B28 LTE-TDD:B38/B40/B41
FMC125-MCIB0: LTE FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28 LTE-TDD:B40
Data transfer LTE: LTE FDD: Max 10Mbps (DL)/Max 5Mbps (UL)
LTE TDD: Max 8Mbps (DL)/Max 2Mbps (UL)
GSM: GPRS: Max 85.6Kbps (DL)/Max 85.6Kbps (UL)
Data support SMS (text/data)
Power
Input voltage range 10 - 30 V DC with overvoltage protection
Internal Back-up battery 170 mAh Li-Ion battery, 3.7 V (0.63 Wh)
Internal fuse 3A, 125V
Power consumption At 12V < 4 mA (Ultra Deep Sleep)
At 12V < 6 mA (Deep Sleep)
At 12V < 12 mA (Online Deep Sleep)
At 12V < 19 mA (GPS Sleep)
At 12V < 36 mA (Nominal with no load)
At 12V < 1A Max. (with full load / Peak)
Bluetooth® Technology
Specification 4.0 + LE
Supported peripherals Temperature and Humidity sensor, OBDII dongle, Inateck Barcode Scanner, Universal Bluetooth® LE sensors support
Physical specification
Dimensions 65 x 56.6 x 20.6 mm (L x W x H)
Weight 62 g
Operating environment
Operating temperature (without battery) -20 °C to +85 °C
Storage temperature (without battery) -20 °C to +85 °C
Operating temperature (with battery) -20 °C to +40 °C
Storage temperature (with battery) -20 °C to +40 °C
Operating humidity 5% to 95% non-condensing
Ingress Protection Rating IP41
Battery charge temperature 0 °C to +45 °C
Battery discharge temperature -20 °C to +60 °C
Battery storage temperature -20 °C to +45 °C for 1 month
-20 °C to +35 °C for 6 months
Interface
Digital Inputs 2
Digital Outputs 1
Analog Inputs 1
CAN Adapter Inputs 1
1-Wire 1
RS232 1
RS485 1
GNSS antenna Internal High Gain
Cellular antenna Internal High Gain
USB 2.0 Micro-USB
LED indication 2 status LED lights
SIM 2x SIM Card (Dual-SIM)
Memory 128MB internal flash memory
Features
Sensors Accelerometer
Scenarios Green Driving, Over Speeding detection, GNSS Fuel Counter, DOUT Control Via Call, Excessive Idling detection, Immobilizer, iButton Read Notification, Unplug detection, Towing detection, Crash detection, Auto Geofence, Manual Geofence, Trip Management
Module
Name FMC125-MBIB0: MeiG SLM320-E with Teltonika TM2500
FMC125-MCIB0: MeiG SLM320-LA with Teltonika TM2500
Technology
Technology LTE(CaT1)/2G(GSM/GPRS)/GNSS/BLUETOOTH® LE
GNSS
GNSS GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS
Receiver 33 tracking channel, 99 acquisition channel
Tracking sensitivity -165 dBM
Position Accuracy < 2.5 m CEP
Velocity Accuracy < 0.1 m/s (within +/- 15% error)
Hot start < 1 s
Warm start < 25 s
Cold start < 35 s
Cellular
Technology LTE Cat 1, GSM
2G bands FMC125-MBIB0: GSM: B2/B3/B5/B8
FMC125-MCIB0: GSM: B2/B3/B5/B8
4G LTE bands FMC125-MBIB0: LTE FDD: B1/B3/B7/B8/B20/B28 LTE-TDD:B38/B40/B41
FMC125-MCIB0: LTE FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28 LTE-TDD:B40
Data transfer LTE: LTE FDD: Max 10Mbps (DL)/Max 5Mbps (UL)
LTE TDD: Max 8Mbps (DL)/Max 2Mbps (UL)
GSM: GPRS: Max 85.6Kbps (DL)/Max 85.6Kbps (UL)
Data support SMS (text/data)
Power
Input voltage range 10 - 30 V DC with overvoltage protection
Internal Back-up battery 170 mAh Li-Ion battery, 3.7 V (0.63 Wh)
Internal fuse 3A, 125V
Power consumption At 12V < 4 mA (Ultra Deep Sleep)
At 12V < 6 mA (Deep Sleep)
At 12V < 12 mA (Online Deep Sleep)
At 12V < 19 mA (GPS Sleep)
At 12V < 36 mA (Nominal with no load)
At 12V < 1A Max. (with full load / Peak)
Bluetooth® Technology
Specification 4.0 + LE
Supported peripherals Temperature and Humidity sensor, OBDII dongle, Inateck Barcode Scanner, Universal Bluetooth® LE sensors support
Physical specification
Dimensions 65 x 56.6 x 20.6 mm (L x W x H)
Weight 62 g
Operating environment
Operating temperature (without battery) -20 °C to +85 °C
Storage temperature (without battery) -20 °C to +85 °C
Operating temperature (with battery) -20 °C to +40 °C
Storage temperature (with battery) -20 °C to +40 °C
Operating humidity 5% to 95% non-condensing
Ingress Protection Rating IP41
Battery charge temperature 0 °C to +45 °C
Battery discharge temperature -20 °C to +60 °C
Battery storage temperature -20 °C to +45 °C for 1 month
-20 °C to +35 °C for 6 months
Interface
Digital Inputs 2
Digital Outputs 1
Analog Inputs 1
CAN Adapter Inputs 1
1-Wire 1
RS232 1
RS485 1
GNSS antenna Internal High Gain
Cellular antenna Internal High Gain
USB 2.0 Micro-USB
LED indication 2 status LED lights
SIM 2x SIM Card (Dual-SIM)
Memory 128MB internal flash memory
Features
Sensors Accelerometer
Scenarios Green Driving, Over Speeding detection, GNSS Fuel Counter, DOUT Control Via Call, Excessive Idling detection, Immobilizer, iButton Read Notification, Unplug detection, Towing detection, Crash detection, Auto Geofence, Manual Geofence, Trip, Jamming detection (Jamming detection supported with SLM320-E and SLM320-LA modules)
Sleep modes GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep
Configuration and firmware update FOTA Web, FOTA, Teltonika Configurator (USB, Bluetooth® wireless technology)
SMS Configuration, Events, DOUT control, Debug
GPRS commands Configuration, DOUT control, Debug
Time Synchronization

GNSS, NITZ, NTP
Fuel monitoring LLS (Analog), Digital LLS (RS232, RS485), LV-CAN200, ALL-CAN300, CAN-CONTROL, OBDII dongle
Ignition detection Digital Input 1, Accelerometer, External Power Voltage, Engine RPM (CAN Adapters, OBDII dongle)
RS232 Modes Log Mode, NMEA, LLS, LCD, RFID HID/MF7, Garmin FMI, TCP ASCII/Binary, Satellite Backup (Iridium Edge)
RS485 Modes

Log Mode, NMEA, LLS, TCP ASCII/Binary
Device Type
Tracker
Antenna
Internal GNSS
Internal GSM
Connectivity
4G LTE bands
Hardware inputs
Analog input
Digital input-DIN
Digital output
RS-232
RS-485
Bluetooth
4.0+LE
Connector Type
Wired
SIM Card
Dual SIM Card
Ingress Protection
IP41
Battery capacity
170 mAH Li-ion 3.7V
Memory
128MB internal flash memory
Supported accessories
1-Wire RFID/iButton
Teltonika DualCam
Driving behavior
Crash detection
Excessive Idling detection
Over Speeding detection
Trip
Vehicle protection
Auto Geofence
Immobilizer
Manual Geofence
Towing Detection
Unplug detection
