ECAN02

New-generation warranty-friendly CAN adapter for contactless access to CAN bus data

Contactless CAN reading

Now the device reads up to 100% of available CAN data in 1000 kb/s

LED indicators

Know exactly if you had installed the adapter properly to define when the data is being transmitted

WARRANTY-FRIENDLY

No physical wire connections, the original wires are intact to make sure you keep the car warranty

UPGRADED CASING

New, stronger, and more robust casing, which improves the longevity of the device

PRODUCT SPECIFICATIONS

SUITABLE FOR
Supported by LV-CAN200, ALL-CAN300, FMB641, FMX650, FMB140, FMB240, FMX150
POWER
Input voltage range 10–30 V DC
Power consumption

At 12V < 1,47 mA (Standby)

At 12V < 4,21 mA (Working)

PHYSICAL SPECIFICATION
Dimensions 39.0 x 19.0 x 12.0 mm (L x W x H)
Weight
16,1 g
OPERATING ENVIRONMENT
Operating temperature (without battery) -40°C to +85°C
Operating humidity

Max 85% non-condensing

TECHNICAL DATA
Features
  • ECAN02 collects vehicle data from CAN bus without damaging the wires
  • Powered from on-board power source
  • Reads the signals through the isolation of CAN bus wires
  • Easy to install and operate
  • CAN-BUS speeds from 33 to 1000 kb/s
  • Automatically adjusts signal level and speed

Device Type
Tracker
Operating Temperature
-40° to 85°C
Input Voltage
10–30 V DC
ECAN02
