POE-173S-12V Planet 1 port 10/100/1000 Mbps 802.3bt PoE++Splitter

POE-173S-12V 1 port 10/100/1000 Mbps 802.3bt PoE++Splitter

Stable DC 12V Power Output Voltage
PLANET POE-173S-12V Gigabit 802.3bt PoE++ splitter, which delivers the Ethernet digital data and PoE power from an 802.3bt type-4 PoE++ PSE (power source equipment) over an UTP cable, comes with a DC 12V output, enabling to deliver a maximum of 60-watt power output to a non-PoE device.

UL Certification
The POE-173S-12V is UL-certified, meaning our dedication to safety and quality is unwavering. Meeting UL's rigorous standard ensures PLANET’s product is cutting-edge, reliable, and secure in any setting whether it is deployed in the office or residential building.

Gigabit 802.3bt PoE++ Network Deployment
The POE-173S-12V, when working with PLANET 802.3bt type-4 PoE++ switches or injectors, offers more network applications to client devices, such as

• PTZ speed dome camera
• Thin client
• AIO (All-in-One) touch PC
• Remote digital signage display
• Non-PoE network devices that need higher power to work normally

The POE-173S-12V frees the network device deployment from restrictions of power outlet locations, thus eliminating the costs for additional AC wiring and reducing the installation time.

• Complies with 802.3bt Power over Ethernet plus plus PD
• Splits the PoE power over RJ45 Ethernet cable into DC 12V output
• PoE usage level LED indicators
• FCC Class B, CE, CB and UL certifications
• Compact metal case
• Desktop, wall-mount or DIN-rail (optional) application

Features

Environment-friendly Structure

The POE-173S-12V comes with a compact-sized metal housing, making the placement of the unit convenient. It features a ventilated construction in which a cooling fan is not necessary, thereby making its operation noiseless. Moreover, the POE-173S-12V is able to operate reliably and stably without affecting its performance. The deployment of non-PoE equipment with constant power feeding can be easily and quickly done.

Interface

• 2 RJ45 interfaces
  • 1-port data + power input
  • 1-port data output
• 1-port DC plug-in

Power over Ethernet

• Complies with 802.3bt Power over Ethernet plus plus PD
• Backward compatible with 802.3at PoE+ with up to 30-watt power output
• Splits the PoE power over RJ45 Ethernet cable into DC 12V output
• Distance up to 100 meters

Hardware

• Metal case
• All-in-one compact size design
• PoE usage level LED indicators
• Desktop, wall-mount or DIN-rail (optional) design
• Complies with FCC, CE class B, CB and UL certifications
