Planet 802.3af Gigabit PoE Injector

1000Mbps 802.3af Power over Ethernet Injector

The POE-152 is an IEEE 802.3af Power over Ethernet Injector which provides DC 48V over Ethernet cables. The POE-152 IEEE 802.3af Power over Ethernet Injector inserts DC Voltage into Cat.5 cable, allowing the cable between the Injector (POE-152) and Splitter (POE-152S-5V/12V) to transfer data and power simultaneously. The maximum distance between the Injector (POE-152) and Splitter (POE-152S-5V/12V) is 100 meters. With POE-152 being installed, it combines the Ethernet digital data with power over the twisted pair cables as an IEEE 802.3af Power over Ethernet Injector. And the IEEE 802.3af Power over Ethernet splitter shall separate the digital data and the power into two outputs.

Unlike existing Power over Ethernet Injector, the POE-152 also provides 1000Mbps Gigabit Ethernet connection ability, except the 10/100Mbps Fast Ethernet connection ability.

With IEEE 802.3af Power over Ethernet devices installed, the system administrator only has to use a single RJ-45 Ethernet cable to carry both power and data to each device. Besides, to connect through POE-152 and POE-152S-5V/12V, you could also have benefits which includes cost saving, easy for networking planning and higher reliability. Upon any IEEE 802.3af devices installed, the POE-152 or together with POE-152S-5V/12V can make the connection while migrating or splitting the power and the Ethernet digital packets, such as connecting the POE-152 to an IEEE 802.3af complied devices, AP or IP phone.
