Ubiquiti 24-Port Gigabit Switch with 16-Port 802.3at PoE+ 2-Port SFP Layer 2 Switch

Ubiquiti 24-Port gigabit switch is a configurable Gigabit Layer 2 switch with twenty-four gigabit ethernet ports including sixteen auto-sensing 802.3at PoE+ ports, and two SFP ports. It provides Gigabit PoE links to your RJ45 Ethernet devices and Gigabit fiber uplink options to your enterprise network. The USW-24-POE features a 1.3" touch LCM to provide status information. With a depth of 7.9", the compact fanless design can be easily installed in a SOHO rack cabinet.

Specifications

• Interfaces:
• Networking: (24) 10/100/1000 RJ45 Ports (2) 1G SFP Ethernet Ports
• Management: Ethernet In-Band
• Total Non-Blocking Throughput: 26 Gbps
• Switching Capacity: 52 Gbps
• Forwarding Rate: 38.69 Mpps
• Power Method: 100-240VAC, 50/60 Hz, Universal Input
• Power Supply: AC/DC, Internal, 120W
• Voltage Range: 100 to 240VAC
• Max Power Consumption (Excluding PoE Output): 25W
• LEDs:
• System: Status
• RJ45 Data Ports: PoE; Speed/Link/Activity
• SFP Data Ports: Link/Activity
• ESD/EMP Protection: Air: ± 16 kV, Contact: ± 12 kV
• Shock and Vibration: ETSI300-019-1.4 Standard
• Operating Temperature: 5 to 40° C (23 to 104° F)
• Operating Humidity: 10 - 90% Noncondensing



PoE

• Total Available PoE: 95W
• PoE Interfaces Ports 1-16: PoE+ IEEE 802.3af/at (pins 1, 2+; 3, 6-)
• Max. PoE Wattage per Ports by PSE 802.3at: 32W
• Voltage Range:
    802.3af Mode: 44-57V
    802.3at Mode: 50-57V

Product Includes

• (1) Ubiquiti UniFi 24-Port PoE Switch
• (2) Rack-Mount Brackets
• (8) Bracket Screws
• (4) Mounting Screws
• (4) Cage Nuts
• (1) Power Cord
