UCG-Max
In Stock
$514.80
Tax included

UCG-Max Controller Cloud Gateway Max

Compact 2.5G Cloud Gateway with 30+ UniFi device / 300+ client support, 1.5 Gbps IPS routing, and selectable NVR storage.

Features:

  • Includes full UniFi application suite for device management

  •  Manages 30+ UniFi devices and 300+ clients

  • 1.5 Gbps routing with IDS/IPS

  • Multi-WAN load balancing

  • 512 GB NVMe SSD storage for NVR

  • 0.96" LCM status display

  • USB-C powered (adapter included)

*Note: The 5-year UI Care service must be applied before the product is opened and activated. FOR NEW SALES ONLY!

Related Products & Accessories



UCG-Max


Technical Specifications
Mechanical
Dimensions 141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2")
Weight 519 g (1.1 lb)
Enclosure material Polycarbonate
Hardware
Processor Quad-core ARM® Cortex®-A53 at 1.5 GHz
System memory 3 GB DDR4
On-board storage 512 GB NVMe SSD
Management interface Ethernet
Bluetooth
Networking interface LAN:
(4) 1/2.5 GbE RJ45 ports

WAN:
(1) 1/2.5 GbE RJ45 port
IDS/IPS throughput 1.5 Gbps*
*Measured with iPerf3 on a DHCP network. Performance may be reduced with PPPoE depending on ISP implementation.
Power method USB type C (5V DC/5A)
Supported voltage range 100–240V AC
Max. power consumption 16.1W
LCM display 0.96" status display
Button Factory reset
Ambient operating temperature -10 to 40° C (14 to 104° F)
Ambient operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
Gateway Features
Performance Redundant WAN with failover and load balancing
WiFi QoS with UniFi APs
Application, domain, and country-based QoS
Application and device type identification
Additional internet failover with LTE Backup
Internet quality and outage reporting
Next-generation security Application-aware firewall rules
Signature-based IPS/IDS threat detection
Content, country, domain, and ad filtering
VLAN/subnet-based traffic segmentation
Full stateful firewall
Advanced networking License-free SD-WAN
WireGuard, L2TP and OpenVPN server
OpenVPN client
OpenVPN and IPsec site-to-site VPN
One-click Teleport and Identity VPN
Policy-based WAN and VPN routing
DHCP relay
Customizable DHCP server
IGMP proxy
IPv6 ISP support
LEDs
Ethernet Green: link/activity
Application Requirements
Mobile app UniFi iOS™ and Android™: Version 10.17.2 and later

Device Type
Gateway
810084697122
