Grandstream GWN7721P 10-Port Layer 2 Lite Managed Switch 8×2.5G Ethernet PoE 2×10G SFP+ Smart VLAN & QoS SMB Networks

GWN7721P
Last items in stock
$240.90
Tax included

GWN7721P

The GWN7721P are 10-port Layer 2 Lite Managed Switches, equipped with 8x 2.5G Ethernet ports and 2x 10Gigabit SFP+ ports, suitable for small-to-medium businesses to build scalable, secure, and smart networks. These devices support complex VLAN traffic segmentation, integrate Port-based, DSCP/802.1p QoS priority management modes, and bandwidth control which greatly improving the overall network performance. Support IGMP Snooping and comprehensive security protection. The GWN7721P model’s 8 Ethernet ports all support PoE power output, suitable for devices such as IP phones, cameras, and Wi-Fi access points. The GWN7721P are easy to manage through the local web user interface, GWN Manager and the cloud using the Grandstream Device Management System (GDMS). The series support both desktop and wall-mount installations and are widely applicable in network construction scenarios across industries such as hotels, home offices, and small to medium-sized enterprises.

Key Features:

  • 8x 2.5Gigabit Ethernet ports and 2x 10Gigabit SFP+ ports
  • GWN7721P ports 1-8 support PoE, smart power control to support dynamic PoE/PoE+ power allocation per port
  • Supports Loop Detection, Cable Test and Port Mirror to quickly locate network faults
  • SNMPv2 remote monitoring, fault diagnosis, configuration management
  • STP/RSTP to guarantee fast convergence, ensure network stability and provide link load balance



GWN7721P Grandstream 10-Port Layer 2 Lite Managed Switch 8×2.5G Ethernet PoE  2×10G SFP+  Smart VLAN & QoS SMB Networks

Product Specifications
Network Protocol IPv4, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
2.5 Gigabit Ethernet Ports 8
10 Gigabit SFP+ Ports (Max Supported Modules) SM-10G: 2
MM-10G: 2
RJ45-10G: 1
PoE Out Ports
Power Supply Internal 110–220V AC
Max Total PoE Output Power 130W
Auxiliary Ports 1x Reset Pinhole
Total Non-Blocking Throughput 40Gbps
Forwarding Mode Store-and-forward
Switching Capability 80Gbps
Jumbo Frame 1518 / 2048 / 3072 / 4096 / 5120 / 6144 / 7168 / 8192 / 9216
Forwarding Rate 59.52 Mpps
Packet Buffer 8Mb
MAC Address Capacity 16K
VLAN Supports up to 32 VLANs (out of 4K VLAN IDs)
Port-based VLAN, 802.1Q VLAN
DHCP Snooping
LAG 5
Multicast IGMP Snooping, Report Message Suppression
QoS Auto prioritization of incoming port
Priority mapping
Queue scheduling (SP, WFQ)
Port priority, 802.1P, DSCP priority
Bandwidth control, Rate limit
DHCP DHCP Client
Maintenance Backup/Restore, System Reboot, Factory Reset, Firmware Upgrade
MAC Address Search, SNMP, LLDP
Monitoring Port statistics, Port mirroring, Cable test, Ping
Security DHCP Snooping, Spanning Tree, Loop Prevention
PoE Watchdog, Kensington Security Slot
Mounting Desktop / Wall-Mount / Rack-Mount
LED Indicators Per Device: Power - Green
Per Port: Link/Activity - Green
Ports 1–8 PoE Power State - Yellow
Operating Temperature 0 to 45°C (32 to 113°F)
Storage Temperature -20 to 60°C (-4 to 140°F)
Operating Humidity 10% to 90% Non-condensing
Storage Humidity 10% to 90% Non-condensing
Dimensions (Unit) 280 x 180 x 44 mm
Dimensions (Package) 361 x 195.5 x 52 mm
Enclosure Metal
Package Content & Weight Unit: 1.45 KG
Entire Package: 2.06 KG
Includes: 1x Switch, 1x 1.2m AC Cable, 1x Ground Cable, 4x Rubber Feet, 2x Lug Ear, 1x QIG
Compliance FCC, CE, RCM, IC
GWN7721P
