ITS-6326-16T-LV, Industrial M12 PoE Switch

The ITS-6326-16T-LV Industrial Managed Switch, is specifically designed for railway system with 16-Port 10/100/1000T M12 ports (dual voltage input 24-54 VDC).



ITS-6326-16T-LV,Industrial M12 PoE Switch

Advanced Layer 3 Managed PoE Switch for Railway Transportation and Harsh Environments

PLANET ITS-6326 Industrial Managed Switch Series, featuring 10G M12 connector and Q-ODC (Quad Optical Direct Connect), is specifically designed for railway system. Compliant with EN50155, EN45545-2, and IEC 61373 standards, it offers robust features tailored to excel in demanding environments. This series supports dual-stack management for both IPv6 and IPv4, incorporates built-in Layer 3 OSPFv2 dynamic routing, and is powered by a high-performance Layer 2/Layer 4 Gigabit switching engine.

This series provides extensive functionality, making it ideal for both railway and heavy industrial applications. Equipped with M12 X-code and Q-ODC connectors for each port, it ensures reliable and stable performance. With the capability to operate seamlessly in extreme temperatures ranging from -40 to 70°C, it offers exceptional adaptability, durability, and silent operation, making it suitable for the harshest industrial conditions.

Also, this series is available in three distinct models, as detailed in the table below. This variety provides users with the flexibility to choose the model that best meets their specific needs.

High-performance 10Gbps Ethernet Capability

Some models in the ITS-6326 series include two 10G M12 ports and two Q-ODC slots, designed with a high-performance switch architecture that provides non-blocking switch fabric and wire-speed throughput of up to 112Gbps. This robust capability effectively simplifies LAN upgrades to accommodate increasing bandwidth demands.

Each 10G M12 port supports four transmission speeds: 1GBASE-T, 2.5GBASE-T, 5GBASE-T, and 10GBASE-T, offering administrators the flexibility to choose the appropriate speed for efficient network expansion. Additionally, the 10G Q-ODC slots exclusively accommodate 10GBASE-SR/LR single-mode fiber transceivers.Engineered for reliability in challenging conditions, it serves as the ideal solution for railway on-board and trackside applications, as well as for vehicles and other demanding industrial environments.

Redundant Ring, Fast Recovery for Critical Network Applications

The ITS-6326 series supports redundant ring technology and features robust, rapid self-recovery capabilities to prevent interruptions and external intrusions, it incorporates the advanced ITU-T G.8032 ERPS (Ethernet Ring Protection Switching) technology, Spanning Tree Protocol (802.1s MSTP), and dual power input into an industrial automation network to enhance system reliability and uptime in harsh factory environments. In a simple ring network, the recovery time of data link can be as fast as 10ms.

Cybersecurity Network Solution to Minimize Security Risks

The industrial managed switch supports SSHv2, TLS and SSL protocols to provide strong protection against advanced threats. In addition, it includes a range of cybersecurity features such as DHCP Snooping, IP Source Guard, ARP Inspection Protection, 802.1x port-based and MAC-based network access control, RADIUS and TACACS+ user accounts management, SNMPv3 authentication, and so on to complement it as an all-security solution.

Layer 3 Routing Support

The ITS-6326 series empowers administrators to enhance network efficiency by manually configuring Layer 3 IPv4/IPv6 VLAN static routing or automatically setting up RIP (Routing Information Protocol) and OSPF (Open Shortest Path First).The RIP uses hop count as a routing metric and prevents routing loops by limiting the number of hops permitted in a path from source to destination.The OSPF, a dynamic interior routing protocol for autonomous systems, operates based on link-state information. It builds a link-state database through the exchange of link-state data among Layer 3 switches and applies the Shortest Path First algorithm to generate a route table from this database.

Robust Layer 2 Features

The ITS-6326 series can be programmed for advanced switch management functions such as dynamic port link aggregation, 802.1Q VLAN and Q-in-Q VLAN, Multiple Spanning Tree protocol (MSTP), loop and BPDU guard, IGMP snooping, and MLD snooping. Via the link aggregation, the ITS-6326 Series allows the operation of a high-speed trunk to combine with multiple ports, and supports fail-over as well.  Also, the Link Layer Discovery Protocol (LLDP) is the Layer 2 protocol included to help discover basic information about neighboring devices on the local broadcast domain.

User-friendly Management Interfaces

For efficient management, this series is equipped with console, Web and SNMP management interfaces.

  • With the built-in Web-based management interface, the ITS-6326 series offers an easy-to-use, platform-independent management and configuration facility.
  • For text-based management, the switches can be accessed via Telnet and the console port.
  • For standard-based monitor and management software, it offers SNMPv3 connection which encrypts the packet content at each session for secure remote management.

Moreover, the ITS-6326 PoE Series offers secure remote management by supporting SSHv2, TLSv1.2 and SNMP v3 connections which encrypt the packet content at each session.

IPv6/IPv4 Dual Stack Management

Supporting both IPv6 and IPv4 protocols, the ITS-6326 series helps the SMBs to step in the IPv6 era with the lowest investment as its network facilities need not be replaced or overhauled if the IPv6 FTTx edge network is set up.

Powerful Security

Offering comprehensive Layer 2 to Layer 4 Access Control List (ACL) features for enforcing security at the edge, it can restrict network access by denying packets based on source and destination IP addresses, TCP/UDP ports, or predefined typical network applications. Its protection mechanism also includes 802.1x port-based and MAC-based user and device authentication. With the private VLAN function, communication between edge ports is prevented, ensuring user privacy. Network administrators can now build highly secure corporate networks with significantly less time and effort than before.

1588 Time Protocol for Industrial Computing Networks

The ITS-6326 series is ideal for telecom and Carrier Ethernet applications, supporting MEF service delivery and timing over packet solutions for IEEE 1588 and synchronous Ethernet.

Modbus TCP Provides Flexible Network Connectivity for Factory Automation

With the supported Modbus TCP/IP protocol, the ITS-6326 series can easily integrate with SCADA systems, HMI systems and other data acquisition systems in factory floors. It enables administrators to remotely monitor the industrial Ethernet switch’s operating information, port information and communication status, thus easily achieving enhanced monitoring and maintenance of the entire factory.

SMTP/SNMP Trap Event Alert

The ITS-6326 series provides event alert function to help to diagnose the abnormal device owing to whether or not there is a break of the network connection, or the rebooting response.

Intelligent SFP Diagnosis Mechanism

The ITS-6326 series supports SFP-DDM (Digital Diagnostic Monitor) function that greatly helps network administrator to easily monitor real-time parameters of the SFP+ transceivers, such as optical output power, optical input power, temperature, laser bias current, and transceiver supply voltage.

Digital Input and Digital Output for External Alarm

This external alarm system enables users to utilize a Digital Input to monitor and log the status of external devices, such as door intrusion detectors, and send event alarms to administrators. The Digital Output can be used to alarm administrators of any changes in link status, whether the link is down or up, on the ITS-6326 series port.

Effective Alarm Alert for Better Protection

The ITS-6326 series includes a Fault Alarm feature that promptly alerts users to any issues with the switches. This valuable functionality eliminates the need for users to spend time identifying the problem, resulting in significant savings in both time and human resources.

Remote Management Solution

PLANET’s Universal Network Management System (UNI-NMS), NMSViewerPro, and CloudViewerPro applications offer comprehensive support for IT staff in effectively managing and monitoring all network devices, including the ITS-6326 series, from remote locations. Designed for deployment in both enterprise and industrial environments where the ITS-6326 series is used remotely, these systems facilitate the identification of bugs or faulty conditions without the necessity of on-site visits. With PLANET’s Remote Management Solution, businesses of all types can now be managed swiftly and efficiently through a unified platform, enhancing operational oversight.

Copper Ports,M12, 8-pin X-coded Female Connector

ITS-6326-16T-WV/ITS-6326-16T-LV:
16 x 10/100/1000BASE-T (Ports 1 to 16)

Console USB Data to RS232 serial port (115200, 8, N, 1)
1 x M12 A-coded 5-pin male connector
Reset Button < 5 sec.: System reboot
> 5 sec.: Factory default
Alarm & DI & DO Ports 1 x M12 A-coded 5-pin male connector for DI/DO and alarm interface
Pin 1 for DI and Pin 2 for DO
Pin 3/4 for Alarm
Pin 5 for GND
Alarm One relay output for port breakdown and power failure.
Alarm relay current carry ability: 1A @ 24V DC
Digital Input (DI) One digital input (DI)
Level 0: -24V~2.1V (±0.1V)
Level 1: 2.1V~24V (±0.1V)
Input load to 24V DC, 10mA max.
Digital Output (DO) One digital output (DO)
Open collector to 24V DC, 100mA max.
Power Connector 1 x M23 A-coded 5-pin male connector
Number of Power Input 2
Power Input Wide Voltage Input (WV Series):
24 to 110 VDC
Low Voltage Input (LV Series):
24 to 54 VDC
Operating Voltage Wide Voltage Input (WV Series):
16.8 to 137.5 VDC
Low Voltage Input (LV Series):
16.8 to 54 VDC
Power Consumption ITS-6326-16T-WV/ ITS-6326-16T-LV:
Max. 23.3 watts / 79.5 BTU (system on)
Max. 29.34 watts / 100.11 BTU (Full loading)
LED System:
PWR1 (Green)
PWR2 (Green
Alarm (Red)
Ring (Green)
R.O. (Green)
I/O (Red)
10/100/1000T M12 Ports:
Up: 1000 LNK/ACT (Green)
10/100 LNK/ACT (Amber)
100/1G/2.5G/5G/10GBASE-T M12 Ports:
Up: 1000 LNK/ACT (Green)
100/10G LNK/ACT (Amber)
Down: 2.5G/5G LNK/ACT (Amber)
10GBASE-X Q-ODC Fiber Port:
Up: LNK/ACT (Amber)
Enclosure IP40 aluminum case
Installation Wall-mount design
Dimensions (W x D x H) 400 x 74 x 195 mm
Weight ITS-6326-16T-LV: 3250g
Switching Specifications
Switch Architecture Store-and-forward
Switch Fabric 112Gbps/non-blocking
ITS-6326-18T2XS-WV
32Gbps/non-blocking
ITS-6326-16T-WV/ ITS-6326-16T-LV
Switch Throughput@64Bytes 83.3Mpps @64 bytes
ITS-6326-18T2XS-WV
23.8Mpps @64 bytes
ITS-6326-16T-WV/ ITS-6326-16T-LV
Address Table 16K entries, automatic source address learning and aging
Shared Data Buffer 32M bits
Flow Control IEEE 802.3x pause frame for full duplex
Back pressure for half duplex
Jumbo Frame
Layer 3 Functions
IP Interfaces Max. 128 VLAN interfaces
Routing Table Max. 128 routing entries
Max. 4K H/W routing table entries
Routing Protocols IPv4 hardware static routing
IPv6 hardware static routing
IPv4 RIPv2
IPv4 OSPFv2 dynamic routing
IPv6 OSPFv3 dynamic routing
Layer 2 Functions
Port Configuration Port disable/enable
Auto-negotiation 10/100/1000Mbps full and half duplex mode selection
Flow control disable/enable
Power saving mode control
Port Status Display each port’s speed duplex mode, link status, flow control status,
auto negotiation status, trunk status
Port Mirroring TX / RX / Both
Many-to-1 monitor
RMirror – Remote Switched Port Analyzer (Cisco RSPAN)
Supports up to 5 sessions
VLAN EEE 802.1Q tag-based VLAN, up to 255 VLAN groups
IEEE 802.1ad Q-in-Q tunneling
Private VLAN Edge (PVE)
MAC-based VLAN
Protocol-based VLAN
Voice VLAN
MVR (Multicast VLAN Registration)
GVRP (GARP VLAN Registration Protocol)
Up to 4K VLAN groups, out of 4094 VLAN IDs
Link Aggregation IEEE 802.3ad LACP/Static Trunk Supports
Static Port Trucking, (20 ports/10 groups max.)
Dynamic LACP-(20 ports/10 groups max.)
Spanning Tree Protocol IEEE 802.1D Spanning Tree Protocol (STP)
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
BPDU Guard
IGMP Snooping IPv4 IGMP (v1/v2/v3) snooping, up to 255 multicast groups
IPv4 IGMP querier mode support
IPv4 IGMP Snooping port filtering
Multicast VLAN Registration
MLD Snooping IPv6 MLD (v1/v2) snooping, up to 255 multicast groups
IPv6 MLD querier mode support
Bandwidth Control Per port bandwidth control
Ingress: 500Kb~1000Mbps
Egress: 500Kb~1000Mbps
Ring Support ERPS, complies with ITU-T G.8032v1 and v2
Recovery time < 50ms
Synchronization IEEE 1588v2 PTP(Precision Time Protocol)
Peer-to-peer transparent clock
End-to-end transparent clock
QoS Traffic classification based, strict priority and WRR
8-level priority for switching
Port number
802.1p priority
802.1Q VLAN tag
DSCP/TOS field in IP packet
Security Functions
Access Control List IP-based ACL/MAC-based ACL
ACL based on:
MAC Address
IP Address
Ethertype
Protocol Type
VLAN ID
DSCP
802.1p Priority
Up to 512 entries
Security Port security
IP source guard, up to 512 entries
Dynamic ARP inspection, up to 1K entries
Command line authority control based on user level
Static MAC address, up to 64 entries
AAA RADIUS client
TACACS+ client
Network Access Control IEEE 802.1x port-based network access control
MAC-based authentication
Local/RADIUS authentication
Management Functions
Basic Management Interfaces Console/ Telnet/ Web browser/ SNMP v1, v2c
Secure Management Interfaces SSHv2, TLS v1.2, SNMP v3
System Management Firmware upgrade by HTTP/TFTP protocol through Ethernet network
LLDP protocol
NTP
PLANET Smart Discovery Utility
PLANET NMS System, NMSViewerPro and CloudViewerPro App
Event Management Remote Syslog
System log
SMTP
ONVIF ONVIF device discovery
ONVIF device monitoring
Floor map
SNMP MIBs RFC 1213 MIB-II
RFC 2863 IF-MIB
RFC 1493 Bridge MIB
RFC 1643 Ethernet MIB
RFC 2863 Interface MIB
RFC 2665 Ether-Like MIB
RFC 2819 RMON MIB (Groups 1, 2, 3 and 9)
RFC 2737 Entity MIB
RFC 2618 RADIUS Client MIB
RFC 2933 IGMP-STD-MIB
RFC 3411 SNMP-Frameworks-MIB
RFC 4836 MAU-MIB
IEEE 802.1X PAE
LLDP
RFC 4292 IP Forward MIB
RFC 4293 IP MIB
Standards Conformance
Regulatory Compliance EMI & EMS FCC Part 15 Class A
Planning:
CE:EN 55032, EN 55035
EN 61000-6-2, EN 61000-6-4
Stability Testing IEC60068-2-32 (free fall)
IEC60068-2-27 (shock)
IEC60068-2-6 (vibration)
Planning:
IEC 61373, EN 50155 (Shock)
IEC 61373, EN 50155 (Vibration)
Railway (Planning) EN 50155, EN50121-4, IEC 60571
Railway Fire Protection (Planning) EN 45545-2
Standards Compliance IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX/100BASE-FX
IEEE 802.3z Gigabit SX/LX
IEEE 802.3ab Gigabit 1000T
IEEE 802.3ae 10GBASE-X
IEEE 802.3an 10GBASE-T
IEEE 802.3bz 2.5/5GBASE-T
IEEE 802.3x flow control and back pressure
IEEE 802.3ad port trunk with LACP
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree Protocol
IEEE 802.1s Multiple Spanning Tree Protocol
IEEE 802.1p Class of Service
IEEE 802.1Q VLAN tagging
IEEE 802.1ad Q-in-Q VLAN stacking
IEEE 802.1X Port Authentication Network Control
IEEE 802.1ab LLDP
IEEE 802.3ah OAM
IEEE 802.1ag Connectivity Fault Management(CFM)
IEEE 802.3az Energy Efficient Ethernet (EEE)
IEEE 1588 PTPv2
RFC 768 UDP
RFC 783 TFTP
RFC 791 IP
RFC 792 ICMP
RFC 2068 HTTP
RFC 1112 IGMP v1
RFC 2236 IGMP v2
RFC 3376 IGMP version 3
RFC 2710 MLD version 1
RFC 3810 MLD version 2
ITU G.8032 ERPS Ring
ITU-T G.8032 ERPS Ring
ITU-T Y.1731 Performance Monitoring
Environment
Operating Temperature: -40 ~ 70 degrees C
Relative Humidity: 5 ~ 95% (non-condensing)
Storage Temperature: -40 ~ 85 degrees C
Relative Humidity: 5 ~ 95% (non-condensing)
Device Type
Network Switch
Device Features
TAA Compliant
Ports
16 10/100/1000T and 1 console port
Type
Managed
Power Consumption
23.2W/79.11BTU
Operating Temperature
-40°C to 70°C
Total PoE Budget
52~56V/Dual power input:320W
Throughput
23.81Mpps @ 64Bytes
Supports
Modbus TCP, IEEE 1588v2 Transparency, ERPS Ring.
Voltage
16.8 to 54 VDC
