PLANET IFB-244-SLC Industrial 2-Channel Optical Fiber Bypass Switch Single Mode LC
PLANET IFB-244-SLC | Planet Technology IFB-244-SLC Industrial 2-Channel Optical Fiber Bypass Switch | WISP Australia
PLANET IFB-244-SLC | Planet Technology IFB-244-SLC Industrial 2-Channel Optical Fiber Bypass Switch | WISP Australia

PLANET IFB-244-SLC Industrial 2-Channel Optical Fiber Bypass Switch Single Mode LC

IFB-244-SLC
Last items in stock
$413.60
Tax included
Planet IFB-244-SLC

PLANET IFB-244-SLC Industrial 2-Channel Optical Fiber Bypass Switch

The IFB-244-SLC is an industrial-grade optical fiber bypass switch with built-in 4 duplex LC connectors, supporting 2-channel duplex or 4-channel simplex connections. It automatically recovers during power loss to maintain network communication and allows replacing the network switch without downtime. Operating in extreme temperatures (-40 to 75°C), it features dual power supply with reverse polarity protection and TAA compliance.

Key Features

  • ✓Speed 100Gbps/40Gbps/10Gbps/1Gbps/100Mbps
  • ✓Interface 4 x Duplex LC

  • ✓ Single Mode

Quantity Unit price You Save
4 $401.19 $49.63

Related Products & Accessories



PLANET IFB-244-SLC

Planet IFB-244-SLC
Planet IFB-244-SLC view 2Planet IFB-244-SLC view 3

The PLANET IFB-244-SLC is a high-performance, industrial-grade optical fiber bypass switch engineered to ensure maximum uptime and high availability in mission-critical network infrastructures. Designed to prevent single points of failure in complex fiber topologies, the device utilizes state-of-the-art fiber-to-fiber technology to provide an automated protection mechanism. In the event of a power outage or local node failure, the IFB-244-SLC instantly reroutes optical traffic, maintaining network continuity across the rest of the loop or ring without human intervention.

This hardware-based, passive optical switching approach guarantees ultra-low insertion losses and ultra-fast switching speeds, making it a transparent and seamless addition to any high-speed industrial network infrastructure.

Technical Specifications

Specification Value
Interface 4 x Duplex LC
Optic Mode Single Mode
Speed  100Gbps/40Gbps/10Gbps/1Gbps/100Mbps
Power Requirements Dual 9-48V DC (with reverse polarity protection), 24V AC
Power Consumption 0.54 watts/1.84BTU
Operating Temperature -40°C to 75°C
Storage Temperature -40°C to 85°C
Humidity 5% to 95% (non-condensing)
Cabling Options IFB-244-SLC/SSC (62.5/125um), IFB-244-MLC/MSC (9/125um)
Dimensions (W x D x H) 32 x 87 x 135 mm
Weight 405g
Standards Conformance FCC Part 15 Class A, CE, IEC60068-2-32 (free fall), IEC60068-2-27 (shock), IEC60068-2-6 (vibration)
