ML2.5-60-19 IgniteNet MetroLinq 2.5G 60 PtP Radio

ML2.5-60-19 - ML2.5-60-19 IgniteNet MetroLinq 2.5G 60 PtP Radio

Product Features:

• Inteference-Free & Unlicensed Band The IgniteNet MetroLinq 60 offers unprecedented performance – combining both the benefits of unlicensed band operation with no interference.

• Dual Band 60GHz & 5GHz Operation! The MetroLinq 60 includes a second 5GHz radio which can be configured as a backup to the 60GHz to provide automatic failover during adverse conditions. This allows links to be extended further without effecting link availability.

• Robust Weather-Resistant Design The MetroLinq 60 features a hybrid metal/plastic design built to withstand the harshest environments including precipitation, hot/cold weather and high/low humidiEes

• Powerful, Flexible Configuration The MetroLinq 60 can operate either as a standalone device or as a coordinated, cloud-managed device, easily meeting the requirements of any installation.

ML2.5-60-19 Features:

• 2.5+Gbps Aggregate throughput; dynamically allocated (60GHz)

• Management VLAN support and VLAN pass-through

• Support Service Provider and Enterprise type networks

• Stand-alone or Cloud-controlled operating modes

• Link failover/backup (60GHz + 5GHz) per client

• 128bit AES Encryption (standard; 5GHz and 60GHz)

• SNMP Monitoring with Private MIB

Product Applications:

• Fixed Wireless Access (broadband)

• 3G/4G Backhaul

• Metro WiFi

• Campus Interconnection

• Hybrid Fiber/Wireless Networks

Product Specifications :

• (1) 2.5 Gigabit Ethernet Port (PoE IN 24-48V)

• (1) SFP Port

• (1) Screw Terminal Block (DC Power IN 24-48V)

• (1) USB 3.0 Port

• Dual flash image support

• LEDs: Power, Ethernet, Wireless, Health/Status

• Dimensions: 190 x 190 x 120mm

• Power: 24-48V/1.5A passive Gigabit PoE or DC

• Operating Temperature: -40 to 70°C

• Storage Temperature: -40 to 70°C

• Operating Humidity: 10 to 90% non-condensing (RH)

• RF Performance (TX):

  60GHz: 14dBm @ 2.5Gbps>5GHz: 27dBm @ 6Mbps, 23dBm @ 866Mbps

• RF Performance (RX):

  60GHz: -74dBm @ MCS1; -60dBm @ MCS9

  5GHz: -94dBm @ MCS0; -72dBm @ MCS15
