MikroTik D53G-5HacD2HnD-TC&R11e-LTE7 Chateau LTE7 CAT7 LTE Router Quad-Core IPQ-4019 Dual-Band Wi-Fi 5× Gigabit RouterOS v7

MikroTik D53G-5HacD2HnD-TC&R11e-LTE7 Chateau LTE7 CAT7 LTE Router Quad-Core IPQ-4019 Dual-Band Wi-Fi 5× Gigabit RouterOS v7

Name: MikroTik D53G-5HacD2HnD-TC&R11e-LTE7 Chateau LTE7 CAT7 LTE Router Quad-Core IPQ-4019 Dual-Band Wi-Fi 5× Gigabit RouterOS v7
Brand: MikroTik
SKU: D53G-5HacD2HnD-TC&R11e-LTE7
Price: 197 AUD
Availability: InStock

Reference D53G-5HacD2HnD-TC&R11e-LTE7

In Stock

$197.00

Tax included

D53G-5HacD2HnD-TC&R11e-LTE7

Chateau LTE7, 5X Gigabit Ethernet Ports, Quad-Core IPQ-4019 448-896 MHz (auto), 256 MB RAM, RouterOS v7, License level 4

This MikroTik Chateau LTE7 is most versatile home router, featuring the new CAT7 modem and a speedy quad-core CPU for all your household network security and management tasks. Dual-band, dual-chain Wi-Fi, 5x Gigabit ports, and full RouterOS v7 features – all at a significantly lower price than the previous LTE6 version.

Perfect for secure VPN work, home offices, or small business networks that care about both function and aesthetics.

Amazing in the hands of seasoned system administrators. Or in a household with zero IT skills. Or anything in-between. Chateau and RouterOS v7 can do it all!

All the new CAT7 devices also support 2×2 MIMO DL and carrier aggregation. That means they can use multiple LTE bands simultaneously. That’s a huge advantage when there are a lot of mobile users in the area. It offers better responsiveness in a crowded environment. And higher efficiency for weaker signal situations in the countryside. Win-win! We have seen Internet speed doubling in rural areas after enabling carrier aggregation.

Key Features:

LTE Cat 7 High-Speed Connectivity
Dual-Band Wi-Fi AC Performance
Powerful Quad-Core Hardware
Advanced RouterOS v7 (Level 4 License)
Extensive LTE Band Support

Quantity	Unit price	You Save
2	$187.15	$19.70
5	$174.35	$113.28
10	$170.41	$265.95
15	$168.44	$428.48
20	$166.47	$610.70

Description
Product Details

D53G-5HacD2HnD-TC&R11e-LTE7 MikroTik Chateau LTE7 CAT7 LTE Router Quad-Core IPQ-4019 Dual-Band Wi-Fi 5× Gigabit RouterOS v7

Product Specifications:

Specification

Details

CPU

Quad-Core IPQ-4019 448–896 MHz (auto)

CPU architecture

ARM 32bit

Size of RAM

256 MB

RAM type

DDR3L

Storage

16 MB Flash

Number of 1G Ethernet ports

USB port

1 (USB 2.0 Type A)

Switch chip model

IPQ-4019

Wireless interface model

IPQ-4019 (2.4 GHz), IPQ-4019 (5 GHz)

Wireless

2.4 GHz 802.11b/g/n dual-chain, 5 GHz 802.11a/n/ac dual-chain

Antenna gain

2.4 GHz – 2 dBi, 5 GHz – 4 dBi

LTE category

Cat 7 (DL: 300 Mbps; UL: 100 Mbps)

LTE modem

R11e-LTE7

TAC

35312597

MIMO DL

2x2

MIMO UL

1x1

LTE FDD bands

1 / 3 / 5 / 7 / 8 / 20 / 28

LTE TDD bands

38 / 40 / 41

3G Category

R8 (DL: 42.2 Mbps; UL: 5.76 Mbps)

3G bands

1 / 3 / 5 / 8

Dimensions

240 × 156 × 44 mm (9.44 × 6.14 × 1.73 in)

Operating system

RouterOS v7 (License level 4)

Operating temperature

-40°C to +70°C

Power

Number of DC inputs

DC jack input voltage

12–28 V

Power adapter nominal voltage

24 V

Power adapter nominal current

1.2 A

Max power consumption (no attachments)

16 W

Max power consumption

21 W

Wireless Specifications – 2.4 GHz

Rate	Tx (dBm)	Rx (dBm)
1 MBit/s	25	-100
11 MBit/s	25	-94
6 MBit/s	26	-95
54 MBit/s	23	-78
MCS0	26	-96
MCS7	22	-73

Wireless Specifications – 5 GHz

Rate	Tx (dBm)	Rx (dBm)
6 MBit/s	26	-96
54 MBit/s	22	-80
MCS0	26	-96
MCS7	21	-75
MCS9	19	-70

Antenna Gain (dBi): 2
4
Device Type: Router
Wireless System: 2.4GHz
5GHz
Ethernet Ports: 5
USB slot: USB 2.0 Type A

MPN D53G-5HacD2HnD-TC&R11e-LTE7
