NE2-D14P Isolated Serial to Ethernet Serial Server & DTU Industrial-Grade Design Modbus Gateway RS232/RS485/RS422
NE2-D14P
NE2-D14P serial port server is used to realize bidirectional transparent transmission of RS485/RS232/RS422 serial port to Ethernet data.The shell adopts three-proof coating, which is Anti-Fungal, Anti-Humidity, and Anti-Salt Spray. It has multiple Modbus gateway modes and MQTTC/HTTPC IoT gateway modes, which can meet the networking functions of various serial port devices/PLCs; it adopts industrial-grade design standards to ensure equipment reliability. The serial port server realizes transparent transmission of serial port data to Ethernet TCP/IP data packets. Users do not need to care about the specific details, and the protocol conversion is completed inside the device.
Key Features:
- Interface signal:RS485/232/422
- Working voltage: DC 8~28V
- Network protocol: TCP/UDP/MQTT/HTTP
NE2-D14P Isolated Serial to Ethernet Serial Server & DTU Industrial-Grade Design Modbus Gateway RS232/RS485/RS422
Specifications:
NE2-D14P Serial to Ethernet Server Specifications | |
---|---|
Product Model | NE2-D14P |
Function | Bi-directional transparent transmission between RS485/RS232/RS422 and Ethernet |
Ethernet Protocol | TCP/IP |
Serial Interfaces | RS485, RS232, RS422 |
Gateway Support | Modbus RTU to Modbus TCP, MQTT Client, HTTP Client |
Design Standard | Industrial-grade |
Protection | Three-proof coating (Anti-Fungal, Anti-Humidity, Anti-Salt Spray) |
Operation Mode | Transparent transmission, protocol conversion handled internally |
Use Case | PLC and serial device networking |
Reliability | High, due to industrial design standards |
