Ubiquiti airFiber X HD 5GHz 2x2 1+ Gigabit PTP Backhaul Radio
AF-5XHD
In Stock
$698.50
Tax included
AF-5XHD
The AF-5XHD from Ubiquiti Networks is an IP67 rated 5GHz carrier radio with LTU technology that delivers up to 1+ Gbps real throughput at distances up to 100 kilometres.
The airFiber 5X HD is managed with the Ubiquiti Network Management System (UNMS). UNMS is a comprehensive management controller featuring an easy-to-navigate graphic user interface. The UNMS app provides instant access to the airOS configuration interface and can be downloaded for iOS and Android. UNMS allows you to set up, configure and manage your airFiber device and offers various configuration options once you're connected or logged in.
AF-5XHD - Ubiquiti airFiber X HD 5GHz 2x2 1+ Gigabit PTP Backhaul Radio
| airFiber | |
|---|---|
| Dimensions | 224 x 82 x 48 mm (8.82 x 3.23 x 1.89") |
| Weight | 0.35 kg (0.77 lb) |
| GPS | External, Magnetic Base |
| Operating Frequency | 5150-5250MHz 5740-5850MHz |
| Power Supply | 24V, 1A PoE Gigabit Adapter (Included) |
| Power Method | Dual Passive Power over Ethernet |
| Maximum Power Consumption | 12W |
| Supported Voltage Range | 20-50VDC |
| Mounting | airFiber X Mount (Rocket Mount Compatible) GPS Pole Mount (Included) |
| Certifications | FCC |
| Operating Temperature | -40 to 55° C (-40 to 131° F) |
| Interface | |
| Data Port | (1) 10/100/1000 Ethernet Port |
| Configuration Port | (1) 10/100/1000 Ethernet Port |
| System | |
| Processor | LTU IC |
| Maximum Throughput | 1+ Gbps |
| Maximum Range | 200+ km (Throughput and range values may vary depending on the environmental conditions) |
| Encryption | 128-bit AES |
| Operating System | airOS F |
| Radio Frequency | |
| Max TX Power | 29 dBm (Dependent on Regulatory Region) |
| Frequency Accuracy | ± 2.5 ppm without GPS Synchronization ± 0.2 ppm with GPS Synchronization |
| Channel Bandwidth | 10/20/30/40/50/60/80/100 MHz Selectable Programmable Uplink and Downlink Duty Cycles |
- Device Type
- PTP/PTMP Radio
- Device Features
- Managed
Outdoor
PoE Powered - MIMO
- 2x2
- Wireless System
- 5GHz
- Ethernet Ports
- 2
817882024396
AF-5XHD
