Ubiquiti UniFi Industrial 10-Port Managed 60W 802.3bt PoE Gigabit Switch
The USW-Industrial from Ubiquiti Networks is a managed Gigabit Layer 2 network switch with auto-sensing, high-power 60W 802.3bt ultra power over Ethernet support. This device has 10 RJ45 ports total, including 8 PoE++ ports ideal for powering devices like UniFi LED panels, cameras and access points. Featuring a ruggedised industrial design, the fanless USW-Industrial is plenum-rated (requires plenum rated cabling for use in plenum spaces) and can be installed in a horizontal or vertical orientation in plenum spaces. Its die-cast aluminium enclosure has a black, powder coated finish, providing greater resistance to corrosion and durability in environments with extreme temperature variation.
USW-Industrial Key Features
- Fanless industrial-grade and plenum-rated design
- 10 Gbps total non-blocking throughput, 20 Gbps switching capacity
- 8-Port auto-sensing 60W 802.bt ultra PoE++
- Device Type
- Network Switch, Power Over Ethernet
- Device Features
- Industrial, Managed
- Power Input
- AC
- POE Ports
- 8, 8
- Power Over Ethernet
- 48V 60W 802.3bt, 48V 15W 802.3af, 48V 60W 802.3at, 48V 30W 802.3at
- Ethernet Ports
- 10, 10
USW-Industrial | |
---|---|
Dimensions | 254 x 235 x 60 mm (10 x 9.25 x 2.36") |
Weight | 3.85 kg (8.49 lb) |
Enclosure Characteristics | Die-Cast Aluminum (ADC12) with Black Powder Coated Finish |
Interfaces |
Networking: (8) 10/100/1000 802.3bt PoE RJ45 Ports, (2) 10/100/1000 RJ45 Ports
Management: Ethernet In-Band
|
Total Non-Blocking Throughput | 10 Gbps |
Switching Capacity | 20 Gbps |
Forwarding Rate | 14.88 Mpps |
Power Method | 100 - 240 VAC, 50/60 Hz Universal Input |
Power Supply | AC/DC, Internal, 450W DC |
Supported Voltage Range | AC Input: 100 to 240VAC, Max. 6A |
Max. Power Consumption (Excluding PoE Output) | 20W |
LEDs | System: Status RJ45 Ports: PoE, Speed/Link/Activity |
ESD/EMP Protection | Air: ± 24 kV, Contact: ± 24 kV |
Shock and Vibration | ETSI300-019-1.4 Standard |
Operating Temperature | Internal AC/DC @ 450W: -40 to 50% C (-40 to 122° F) Internal AC/DC @ 240W: -40 to 60° C (-40 to 140° F) |
Operating Humidity | 5 to 95% Noncondensing |
Certifications | FCC, IC |
PoE | |
PoE Interfaces | PoE++ IEEE 802.3bt (Pair A 1, 2+; 3, 6-) (Pair B 4 , 5+; 7, 8-) |
Max. PoE Wattage per Port by PSE | 802.3bt 60W |
Voltage Range 802.3 PoE Mode | 50-57V |
Max. Total PoE Power Budget | 430W |
