Tycon 10-16VDC IN 802.3af/at PoE DUAL OUT 42W DCDC Converter

TP-DCDC-1248Dx2-HP Dual Output 802.3at PoE Injectors

The TP-DCDC-1248DX2-HP are unique high power PoE injectors with Dual 802.3af/at compatible outputs. This means that two devices can be powered from a single PoE injector. The data path between the units is handled by the injector so no PoE switch is required.

Power Output is 42W total or 21W per port

They have two inputs for connecting 2 power sources, like a primary and backup power source. They have various protections for short circuit, overload and surges caused by ESD or lightning. The built-in surge protection protects sensitive connected devices from damage due to surges on data and PoE lines. All 8 wires are protected.

The input voltage and output voltage are isolated to avoid any grounding or negative voltage issues.

Features of TP-DCDC-1248Dx2-HP:

• Input Voltage 10-16VDC
• Compatible with 802.3af/at
• 2 powered ports, each 21W
• Surge protection to 15kV
• Low self consumption power
• Short Circuit, Over Current and Over Voltage Protection
• High Temperature Operation (up to 70deg C)

Applications:

• Wireless Access Points and Client Devices
• IP Phone and Security Camera System
