GSD-503 PLANET 5-Port 10/100/1000T Gigabit Ethernet Switch

PLANET 5-Port RJ45 Gigabit Ethernet Green Networking Switch

GSD-503
In Stock
$54.99
Tax included

The GSD-503 from PLANET Networking is a Green Networking Switch is specially designed to meet the current trend for energy savings worldwide. The GSD-503, a 5-port Gigabit Ethernet Switch, brings both benefits of energy savings and Gigabit wire speed performance to home networking, SOHOs and enterprises. The GSD-503 incorporates two advanced Green Networking technologies and is able to provide power savings of up to 40% but maintains high performance efficiently:

  • The Hibernation Link Down power saving goes beyond IEEE specifications to automatically lower power for a given port when it is not linked. With the Hibernation Link Down power saving technology, the GSD-503 will automatically adjust power usage of the ports that are shut down or not connected to network device.
  • Intelligent use of power uses an intelligent algorithm that actively determines the appropriate power level based on cable length. When the GSD-503 is connected with Ethernet cable shorter than 20m, a device can obtain maximum power savings because the GSD-503 would automatically detect the Ethernet cable length and diminish power usage. The connected device can substantially reduce the overall power consumption, which makes a significant contribution to energy savings.

Device Type
Network Switch
Ethernet Ports
5
No reviews

Hardware Specifications
Hardware Version 8
10/100/1000BASE-T Ports 5 Auto MDI/MDIX ports
LED Display One for Power, Two for 1000 & Link / Act per port
Enclosure Metal
Dimensions (W x D x H) 155 x 86 x 26mm
Weight (g) 317g
Power Requirements (External power adapter) 5V DC, 1A
Power Consumption/Dissipation 3.3 watts/11 BTU
Switch Specifications
Switch Processing Scheme Store-and-Forward
Address Table 2K
Flow Control Back pressure half duplex, IEEE 802.3x pause frame full duplex
Switch Fabric 10Gbps
Throughput (packet per second) 7.44Mpps
Jumbo Packet Size 9K
Standards Conformance
Standards Compliance IEEE 802.3 (Ethernet)
IEEE 802.3u (Fast Ethernet)
IEEE 802.3ab(Gigabit Ethernet)
IEEE 802.3x (Full-duplex Flow Control)
IEEE 802.3az Energy Efficient Ethernet (EEE)
Regulatory Compliance FCC Part 15 Class B, CE
Environments
Temperature Operating: 0~50 degrees C
Storage: -10~70 degrees C
Humidity Operating: 5% to 95%, Storage: 5% to 95% (non-condensing)
