Omada SG3428X-M2 24× 2.5G Non-PoE L2+ Managed Switch with 4× 10G SFP+
Omada SG3428X-M2 24× 2.5G Non-PoE L2+ Managed Switch with 4× 10G SFP+

Omada SG3428X-M2 24× 2.5G Non-PoE L2+ Managed Switch with 4× 10G SFP+

SG3428X-M2
*** Out of stock ATM, Available On Backorder ***
$693.00
Tax included

SG3428X-M2 v2

The Omada SG3428X-M2 is a high-performance L2+ managed switch featuring 24× 2.5GbE ports and 4× 10G SFP+ uplinks. Designed for high-speed data aggregation and backbone connectivity, it delivers reliable multi-gigabit performance for enterprise, campus, and high-density network environments. As a non-PoE switch, it is ideal for deployments where power delivery is not required, offering a cost-effective solution focused purely on data switching. Integrated with the Omada SDN platform, it enables centralized cloud management and advanced networking capabilities for scalable and efficient network infrastructure.

Key Features

  • ✓24× 2.5 Gbps RJ45 ports
  • ✓4× 10 Gbps SFP+ slots enable high-bandwidth connectivity
  • ✓ 200 Gbps switching capacity
  • ✓Centralised cloud management via the web or the Omada app
  • ✓Standalone management via web, CLI, SNMP, and RMON

Related Products & Accessories



Omada SG3428X-M2 24× 2.5G Non-PoE L2+ Managed Switch with 4× 10G SFP+

Planet GS-6320-24UP2T2XV
The Omada SG3428X-M2 is an enterprise-grade L2+ managed switch built for high-speed networking and scalable infrastructure. Equipped with 24 multi-gigabit 2.5GbE ports, it provides fast and reliable connectivity for modern network devices, including WiFi 6/6E/7 access points, servers, and high-performance workstations.

Featuring 4× 10G SFP+ uplink ports, the switch enables high-bandwidth aggregation and seamless integration into core or distribution layers, making it ideal for enterprise, campus, and high-density network environments.

Unlike PoE-enabled models, the SG3428X-M2 is designed purely for data switching, making it a cost-effective solution where power delivery is not required.

Integrated with the Omada Software Defined Networking (SDN) platform, it supports centralized cloud management via web interface or Omada Controller. Advanced Layer 2+ features such as VLAN, QoS, ACL, and static routing provide enhanced control, security, and optimized traffic management across the network.

Technical Specifications

Specification Value
Ports 24 × 10/100/1000/2.5Gbps RJ45
Uplink Ports 4 × 10G SFP+
Console Ports 1 × RJ45, 1 × Micro-USB
Switching Capacity 200 Gbps
Packet Forwarding Rate 148.8 Mpps
Packet Buffer Memory 16 Mbit
MAC Address Table 32K
Jumbo Frame 9 KB
Power Supply 100–240V AC, 50/60Hz
Power Consumption Max. 45.1 W
Heat Dissipation 154.38 BTU/h
Fan 1 Fan
Mounting Rack Mountable
Dimensions 440 × 180 × 44 mm
QoS 8 Queues, 802.1p, DSCP, SP, WRR, Bandwidth Control
Layer Features L2+ (VLAN, ACL, QoS, Static Routing)
VLAN Support Up to 4K VLANs
Security ACL, 802.1X, DoS Protection, IP-MAC Binding
Management Omada SDN (Cloud, Hardware & Software Controller)
Management Interfaces Web GUI, CLI, SNMP v1/v2c/v3
Operating Temperature 0°C to 40°C
Operating Humidity 10–90% RH non-condensing
Certifications CE, FCC, RoHS
