Mikrotik EC25-EU&KNe Compact Industrial LTE Gateway with GNSS BLE PoE and MIMO for Automation & IoT Applications
Mikrotik EC25-EU&KNe|Mikrotik EC25-EU&KNe Compact Industrial LTE Gateway with GNSS BLE PoE and MIMO for Automation & IoT Applica
Mikrotik EC25-EU&KNe|Mikrotik EC25-EU&KNe Compact Industrial LTE Gateway with GNSS BLE PoE and MIMO for Automation & IoT Applica
  • New
Mikrotik EC25-EU&KNe Compact Industrial LTE Gateway with GNSS BLE PoE and MIMO for Automation & IoT Applications
Mikrotik EC25-EU&KNe|Mikrotik EC25-EU&KNe Compact Industrial LTE Gateway with GNSS BLE PoE and MIMO for Automation & IoT Applica
Mikrotik EC25-EU&KNe|Mikrotik EC25-EU&KNe Compact Industrial LTE Gateway with GNSS BLE PoE and MIMO for Automation & IoT Applica

Mikrotik EC25-EU&KNe Compact Industrial LTE Gateway with GNSS BLE PoE and MIMO for Automation & IoT Applications

EC25-EU&KNe
In Stock
$115.50
Tax included

Mikrotik EC25-EU&KNe

Industrial LTE/BLE/GNSS connectivity that fits anywhere. Originally designed for coffee and vending machines – perfect for all kinds of industrial automation.

Key Features:

  • LTE Cat4 mobile connectivity
  • Gigabit Ethernet
  • GPIO
  • Bluetooth for IoT sensors
  • GNSS/GPS
  • 2x2 MIMO
  • DIN rail mounting supported
  • eSIM + Nano SIM
  • PoE-In

Power Supply Not Included, please select an option from the list below



EC25-EU&KNe Mikrotik Compact Industrial LTE Gateway with GNSS BLE PoE and MIMO for Automation & IoT Applications


KNOT Embedded LTE4 is a tiny but powerful industrial LTE gateway designed for integrators, automation specialists, and IoT system builders. It fits into tight spaces, mounts directly on a DIN rail, and delivers reliable LTE Cat4 connectivity with Bluetooth and GNSS support.

Use it as a primary gateway, a backup link, or an IoT data collection node – everything is powered by RouterOS for maximum flexibility.

KNOT Embedded LTE4 is made for environments where space is limited but reliability is critical:

  • Smart city infrastructure (parking, sensors,metering)
  • Coffee and vending machine monitoring
  • Industrial automation cabinets
  • Environmental & utility monitoring
  • Vehicle or asset tracking with GNSS
  • Retail kiosks, payment terminals, digital signage
  • LTE backup connectivity for existing Ethernet devices
  • IoT gateways for BLE sensors and beacons

Whether you’re building a new system or adding LTE to an existing installation, KNOT Embedded LTE4 adapts easily. It’s easy to integrate, easy to deploy, and built to perform in harsh environments – from smart city deployments to industrial automation and mobile tracking.

Product Specifications:

Product Code EC25-EU&KNe
CPU ARM 32-bit Cortex A7 up to 1.2 GHz
Size of RAM 256 MB
RAM Type DDR
Storage 512 MB
Number of 1G Ethernet Ports 1
GNSS Interface Model EC25-EU
GNSS Standard BeiDou, Galileo, GPS, Glonass
RF Connector Type SMA female
SIM Slots Nano SIM, eSIM
Bluetooth Version 5.4
MIMO DL 2x2
MIMO UL 1x1
Dimensions 90 x 70 x 22 mm
Operating System RouterOS v7, License level 3
Operating Temperature -40°C to +70°C
EC25-EU (EMEA) Bands LTE Category 4 (150Mbps Downlink, 50Mbps Uplink)
1 (2100MHz) / 3 (1800MHz) / 7 (2600MHz) / 8 (900 MHz) / 20 (800MHz) / 28A (700 MHz)
38 (2600MHz) / 40 (2300MHz) / 41 (2500MHz)
3G Category R8 (42.2Mbps Downlink, 5.76Mbps Uplink)
1 (2100MHz) / 8 (900MHz)
2G Category Class12
3 (1800MHz) / 8 (900MHz)
Powering Number of DC Inputs: 2 (PoE-In, USB Type-C (powering only))
PoE-In Input Voltage: 12-57 V
USB Type-C Input Voltage: 5 V
Power Adapter Nominal Voltage: 5 V
Power Adapter Nominal Current: 0.8 A
PoE-in: 802.3af/at
Max Power Consumption: 7 W

Including Parts:

  • K-91Fastening set
  • Power Supply Not Included, please select an option from the list.
4752224009883
EC25-EU&KNe
