MikroTik Chateau LTE7 ax Wi-Fi 6 AX Router with LTE Cat7 2.5G Ethernet 1GB RAM
  • New
MikroTik S53UG+5HaxD2HaxD-TC&R11e-LTE7|MikroTik Chateau LTE7 ax Wi-Fi 6 AX Router with LTE Cat7 2.5G Ethernet 1GB RAM|Wisp Austr
MikroTik Chateau LTE7 ax Wi-Fi 6 AX Router with LTE Cat7 2.5G Ethernet 1GB RAM

MikroTik Chateau LTE7 ax Wi-Fi 6 AX Router with LTE Cat7 2.5G Ethernet 1GB RAM

S53UG+5HaxD2HaxD-TC&R11e-LTE7
Last items in stock
$280.50
Tax included

Chateau LTE7 ax

Chateau LTE7 ax combines the new R11e-LTE7 modem with a quad-core ARM CPU, 1GB of RAM, Wi-Fi 6 (802.11ax) dual-band wireless, and a 2.5 Gigabit Ethernet port for ultra-fast local connections. Run multiple secure VPN tunnels, advanced firewall rules, advanced container setups, or complex routing scenarios – all while enjoying faster and more reliable mobile connectivity. Whether LTE is your primary connection or a rock-solid backup to fiber, Chateau LTE7 ax adapts to your setup effortlessly… and in style!

Key Features:

  • Powerful 1.8 GHz Quad-core ARM CPU
  • Container support
  • Strong Dual-band, Dual-chain radio
  • 4x Gigabit ethernet ports
  • Fast and respondive LTE Cat7 modem
  • 1 GB of RAM



Chateau LTE7 ax MikroTik Wi-Fi 6 AX Router with LTE Cat7 2.5G Ethernet 1GB RAM

With five Ethernet ports (including a 2.5G port), 2×2 MIMO LTE and full RouterOS v7 functionality, Chateau LTE7 ax fits a wide range of use cases:

  • Secure home offices and remote work
  • LTE-based or hybrid ISP deployments
  • Small and medium-sized businesses
  • Households that want performance and clean design

It’s equally comfortable in the hands of seasoned system administrators who need true flexibility – or users who just want to plug it in and forget it’s there.

Chateau supports the TR-069 technology that allows creating custom remote client management options.
You can have the most straightforward and basic router settings on the same web-page that you are using to pay the mobile bill.

The freedom of LTE

Reach consistent speeds of up to 300 Mbps with carrier aggregation, as CAT6 allows devices to use multiple bands simultaneously. That is a huge advantage in areas with many LTE users. Chateau provides better responsiveness in a crowded environment and higher efficiency for weaker signal situations in the countryside.

Depending on the service provider, we have seen Internet speed doubling in rural areas after switching to carrier aggregation, so there is no need to wait for cable network expansions.

Product Specifications:

Specifications
Product code S53UG+5HaxD2HaxD-TC&R11e-LTE7
Architecture ARM 64bit
CPU IPQ-6010
CPU core count 4
CPU nominal frequency Auto MHz
CPU Threads count 4
Switch chip model IPQ-6010
RouterOS license 4
Operating System RouterOS v7
Size of RAM 1 GB
Storage size 128 MB
Storage type NAND
MTBF Approximately 200,000 hours at 25°C
Tested ambient temperature -40°C to 70°C
Powering
Number of DC inputs 1 (DC jack)
DC jack input Voltage 12–28 V
Max power consumption 21.5 W
Max power consumption (without attachments) 15.5 W
Cooling type Passive
Mobile
3G Category R8 (DL: 42.2 Mbps; UL: 5.76 Mbps)
3G Bands 1 (2100 MHz), 5 (850 MHz), 8 (900 MHz), 3 (1800 MHz)
LTE Category 7 (DL: 300 Mbps; UL: 100 Mbps)
MIMO DL 2x2
MIMO UL 1x1
LTE FDD Bands 1, 3, 5, 7, 8, 20, 28, 32
LTE TDD Bands 38, 40, 41
TAC 35312597
Wireless Specifications
2.4 GHz Max data rate 574 Mbit/s
2.4 GHz Number of chains 2
2.4 GHz Standards 802.11b/g/n/ax
2.4 GHz Antenna gain 3 dBi
2.4 GHz Chip model QCN-5022
2.4 GHz Generation Wi-Fi 6
5 GHz Max data rate 1200 Mbit/s
5 GHz Number of chains 2
5 GHz Standards 802.11a/n/ac/ax
5 GHz Antenna gain 6 dBi
5 GHz Chip model QCN-5052
5 GHz Generation Wi-Fi 6
Ethernet
10/100/1000 Ethernet ports 4
Number of 2.5G Ethernet ports 1
Peripherals
Number of SIM slots 1 (Micro SIM)
Number of USB ports 1
USB Power Reset Yes
USB Slot type USB Type A
Max USB current 1 A
Other
CPU temperature monitor Yes
PCB temperature monitor Yes
Voltage Monitor Yes
Mode button Yes
Certification & Approvals
Certification CE, EAC, ROHS
IP IP20

Included Parts:

  • 24V 1.2A power adapter
  • UTP Flat Cable (1.5m)
Antenna Gain (dBi)
3
6
Device Type
Router
Wireless System
2.4GHz
5GHz
Ethernet Ports
1 Port 2.5G
4 Ports 10/100/1000
USB slot
USB 2.0 Type A
S53UG+5HaxD2HaxD-TC&R11e-LTE7
