ASRock Rack X470D4U2 mATX AMD Ryzen 5000 Series Up to 7xSATA 6Gb/s 2x1G LAN IPMI Server Motherboard
ASRock Rack X470D4U2 mATX AMD Ryzen 5000 Series Up to 7xSATA 6Gb/s 2x1G LAN IPMI Server Motherboard
ASRock Rack X470D4U2 mATX AMD Ryzen 5000 Series Up to 7xSATA 6Gb/s 2x1G LAN IPMI Server Motherboard
ASRock Rack X470D4U2 mATX AMD Ryzen 5000 Series Up to 7xSATA 6Gb/s 2x1G LAN IPMI Server Motherboard

ASRock Rack X470D4U2 mATX AMD Ryzen 5000 Series Up to 7xSATA 6Gb/s 2x1G LAN IPMI Server Motherboard

X470D4U2
Out Of Stock
$476.30
Tax included

X470D4U2

  • Micro-ATX (9.6" x 9.6")
  • Supports AMD Ryzen™ 5000 Series Desktop Processors
  • 1 PCIe3.0 x16, 1 PCIe x16 (PCIe3.0 x8), 1 PCIe2.0 x1
  • 2 M.2
  • Up to 7 SATA 6Gb/s
  • 2 RJ45 (1GbE) by Intel® i210
  • Remote management (IPMI)

Related Products & Accessories



X470D4U2 - ASRock Rack mATX AMD Ryzen 5000 Series Up to 7xSATA 6Gb/s 2x1G LAN IPMI Server Motherboard

Specifications



 Physical Status
Form Factor Micro-ATX
Dimensions 9.6'' x 9.6'' (244 mm x 244 mm)
 Processor System
CPU AMD Ryzen™ 5000, 4000 and 3000 G-Series Desktop Processors with Radeon™ Graphics
AMD Ryzen™ 5000 and 3000 Series Desktop Processors
AMD Ryzen™ PRO 5000, 4000 and 3000 Series Desktop Processors
Socket 1 Socket AM4 (PGA 1331)
Thermal Design Power (TPD) 105W
Chipset AMD 4570
 System Memory
Supported DIMM Quantity 4 DIMM slots (2DPC)
Supported Type DDR4 288-pin ECC*/non-ECC UDIMM
Max. Capacity per DIMM 32GB
Max. DIMM Frequency 3200 MHz
Voltage 1.2V
Note * For AMD Ryzen™ Desktop Processors with Radeon Graphics, ECC support is only with Processors with PRO technologies
 PCIe Expansion Slots (SLOT7 close to CPU)
SLOT6 PCIe3.0 x16 [CPU]
SLOT5 PCIe2.0 x1 [FCH]
SLOT4 PCIe x16 (PCIe3.0 x8) [CPU]
Note -SLOT6 will auto-switch to PCIe3.0 x8 when SLOT4 is occupied, and SLOT4 will not function when installing AMD Ryzen™ 3000 G-Series Desktop Processors with Radeon™ Graphics
 Other PCIe Expansion Connectors
M.2 slot 1 M-key (PCIe3.0 x2 or SATA 6Gb/s),supports 22110/2280/2260/2242 form factor [FCH]
1 M-key (PCIe2.0 x4), supports 22110/2280/2260/2242 form factor [FCH]
 SATA/SAS Storage
PCH Built-in Storage AMD X470 (Up to 7 SATA 6Gb/s):
5 SATA 7-pin, 1 SATA DOM, 1 M.2
 Ethernet
Additional Ethernet Controller Intel® i210: 2 RJ45 (1GbE)
USB
Controller/Hub ASPEEDAST2500:
1 DB15 (VGA)
Connectors/headers External:
2 Type-A (USB3.2 Gen1)
Internal:
1 header (19-pin, 2 USB3.2 Gen1)
 Graphics
Controller ASPEED AST2500
 Security
TPM 1 (17-pin, LPC)
 Rear I/O
UID Button/LED 1 UID button w/ LED
Video output 1 DB15 (VGA)
Serial Port 1 DB9 (COM)
USB 2 Type-A (USB3.2 Gen1)
RJ45 2 RJ45 (1GbE), 1 dedicated IPMI
 Hardware Monitor
Temperature CPU, FCH, DDR, MB, Card Side, LAN Temperature sensing
Fan Fan Tachomete
Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature)
Fan Multi-Speed Control
Voltage 3VSB, 5VSB, VCPU, VSOC, VCCM, APU VDDP, PM VDD CLDO, PM VDDCR S5, PM VDDCR, BAT, 3V, 5V, 12V
 Server Management
BMC Controller ASPEED AST2500: IPMI2.0 with iKVM and vMedia support
IPMI Dedicated GLAN 1 Realtek RTL8211E for dedicated management GLAN
 System BIOS
BIOS Type 32MB AMI UEFI Legal BIOS
BIOS Features Plug and Play, ACPI 2.0 compliance wake up events, SMBIOS 2.8, ASRock Rack instant flash
 Internal Connector/Headers
PSU connector 1 (24-pin, ATX main power), 1 (8-pin, ATX 12V)
Auxiliary Panel Header 1 (includes chassis intrusion, location button & LED, front LAN LED, system fault, and BMC alert)
System panel header 1 (RST, PWRBTN, HDDLED, PWRLED)
Fan Header 6 (4-pin)
Buzzer 1
TPM Header 1 (17-pin, LPC)
SMBus header 1
PMBus header 1
IPMB Header 1
Clear CMOS 1 (contact pad)
 LED Indicators
Standby Power LED 1 (5VSB)
80 Debug Port LED 1
Fan Fail LED 6
BMC Heartbeat LED 1
 Environment
Operating temperature 10 - 35°C (50 - 95 degF)
Non-operating temperature -40 - 70°C (-40 - 158degF)







Form Factor
mATX
Ethernet Ports
2
4710483933325
X470D4U2
