ASRock Rack EPYC3451D4I2-2T
Related Products & Accessories
International buyers, please email us for shipping quote
| MB Physical Status | |
| Form Factor | mini-ITX |
| Dimensions | 6.7"x6.7" (170mm x 170mm) |
| Processor System | |
| CPU | AMD EPYC™ Embedded 3451 |
| Socket | SP4 |
| Power Design | TDP 100W |
| Chipset | System on chip |
| System Memory | |
| Capacity | 4 288-pin DDR4 SDRAM DIMMs (1DPC) |
| Type | DDR4 ECC/UDIMM, RDIMM, LRDIMM |
| DIMM Size Per DIMM | ECC/UDIMM: 64GB, 32GB, 16GB, 8GB, 4GB RDIMM: 128GB, 64GB, 32GB, 16GB, 8GB, 4GB |
| DIMM Frequency | ECC/UDIMM: 2666/2400/2133 MHz RDIMM: 2666/2400/2133 MHz *the max speed may vary based on SoC SKU |
| Voltage | 1.2V |
| Expansion Slot | |
| PCIe 3.0 x 16 | SLOT7: PCIe3.0x16 |
| M.2 | 1 M.2 (PCIe3.0x4 or SATA 6Gb/s) |
| Storage | |
| SATA Controller | 14 SATA 6Gb/s (8 from OCulink 8i, 4 from OCulink 4i, 2 from SATA 7-pin*, 1 from M.2*) * One of SATA 7-pin will be disabled when installing M.2 SATA device |
| OCuLink for U.2 | 1 OCulink 8i (PCIe3.0 x8 or 8x SATA 6Gb/s) 1 OCulink 8i (PCIe3.0 x8) 1 OCulink 4i (PCIe3.0 x4 or 4x SATA 6Gb/s) |
| Ethernet | |
| Additional GbE Controller | Intel® X710-AT2: 2 RJ45 (10GbE) |
| Management | 1 RJ45 Dedicated IPMI LAN port via RTL8211E |
| Management | |
| BMC Controller | ASPEED AST2500 |
| IPMI Dedicated GLAN | 1 x Realtek RTL8211E for dedicated management GLAN |
| Graphics | |
| Controller | ASPEED AST2500 |
| Rear Panel I/O | |
| VGA Port | 1 D-Sub |
| USB 3.1 Gen1 Port | 2 Type-A (5Gbps) |
| Lan Port | 2 RJ45 (10GbE) |
| Dedicate LAN | 1 |
| UID Button/UID LED | 1 |
| System BIOS | |
| BIOS Type | 16MB AMI UEFI Legal BIOS |
| BIOS Features | Plug and Play (PnP) ACPI 2.0 Compliance Wake Up Events SMBIOS 2.8 Support ASRockRack Instant Flash |
| Hardware Monitor | |
| Temperature | CPU/DDR Temperature Sensing MB/Card side Temperature Sensing |
| Fan | Fan Tachometer Fan Multi-Speed Control CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature) |
| Voltage | Voltage Monitoring: +12V, +5V, +3.3V, VDDCR_CPU, VDDCR_SOC, VCCM_ABCD, +BAT, 3VSB, 5VSB |
| Environment | |
| Temperature | Operation temperature: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C |
