Alfa AWM27921BU Wi-Fi 6E Bluetooth 5.2 Dual-Band M.2 2230 Module with MediaTek MT7921AUN Chipset (USB Interface)

AWM27921BU
Last items in stock
$53.90
Tax included

AWM27921BU

The AWM27921BU is a WiFi 6E 2x2 dual-band WLAN and Bluetooth v5.2 M.2 module.

Key Features:

  • IEEE 802.11 a/b/g/n/ac/ax compliant
  • Support 20 MHz, 40 MHz, 80 MHz bandwidth in 2.4 GHz, 5 GHz, 6GHz band
  • Support Bluetooth 5.2
  • Dual-band 2T2R mode
  • Data rate up to 800 Mbps with USB3.0
  • Support STBC, LDPC, TX Beamforming, and RX Beamforming
  • Bluetooth v5.2 with BLE (BT low energy)
  • Support BT/BLE dual mode
  • Support BT/Wi-Fi coexistence

Keypoint

  • MediaTek MT7921AUN chipset
  • 2x Wi-Fi IPEX4 (MHF4) connector
  • 2x BT IPEX4 (MHF4) connector
  • M.2/NGFF B-key 2230

Related Products & Accessories



AWM27921BU - Wi-Fi 6E Bluetooth 5.2 Dual-Band M.2 2230 Module with MediaTek MT7921AUN Chipset (USB Interface)

Product Specifications

Feature Description
Chipset MediaTek MT7921AUN
IEEE 802.11 Standards a/b/g/n/ac/ax
Frequency 2.4 GHz
5 GHz
6 GHz
Bluetooth v5.2
Data Rate 11b: 1, 2, 5.5, 11 Mbps
11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
11n: up to 300 Mbps
11ac: up to 866.7 Mbps
11ax (2.4 GHz): up to 573.5 Mbps
11ax (5 GHz): up to 1201 Mbps
Form Factor M.2 B-key (USB bus)
Antenna Connector 2x IPEX (Wi-Fi)
2x IPEX (BT)
Dimensions 22 x 30 x 2.8 mm
Operating Temperature -25 °C to 75 °C
Operation Voltage 3.3 V
Power Consumption 755 mA (max.)
Operating Systems Microsoft Windows 10/11
Linux
Wireless System
2.4GHz
5GHz
6GHz
AWM27921BU
