POE-EXT-GD-HP

Power Over Ethernet (PoE) Extender, Gigabit, 802.3at Compatible input and output, 2 Pair or 4 Pair input, -40C to +70C operating Temp, Weatherproof IP66

key Features:

  • PoE Injector
  • 802.3af / 802.3at Compatible
  • 10/100/1000Mb Compatible
  • Weatherproof – Outdoor rated
  • Easy Plug & Play Operatio
  • Extends PoE an additional 100m

Applications:

  • Wireless Equipment
  • IP Telephone
  • Security Applications
  • Sensor Equipment
  • PoE Lightin

Quantity Unit price You Save
5 $176.06 $27.23


POE-EXT-GD-HP Tycon Gigabit 802.3at PoE Extender 2-Pair/4-Pair Input IP66 Weatherproof

The POE-EXT-GD-HP is a high quality, high power, shielded Gigabit Ethernet and PoE extender to be able to extend Ethernet beyond the standard 100m limit. By using multiple units, Ethernet and PoE can be extended up to 300m over CAT5/CAT6 cables. The units are powered by PoE so no additional power source is required. Units can accept Mode A (Pins 1,2,3,6) or Mode B (Pins 4,5,7,8) PoE: 802.3af, 802.3at or 48V Passive PoE. The rugged outdoor weatherproof enclosures are powder coated aluminum and are rated to IP66. The units meet outdoor temperature.ratings of -25C to +55C.

Product Specifications:

Specification Details
PoE Input 802.3af / at / 44 to 57V Passive
PoE Output 802.3af or 802.3at Class 4
PoE Output Pinout 1,2(+) 3,6(-) Up to 25W
Self Consumption Power 2.0W Typ
Operating Temperature -13°F to 131°F (-25°C to +55°C)
Operating Humidity 0 to 100% RH
Size 7.3 x 1.8 x 1.8” (185x45x45mm)
Weight 8.5oz (240g)
Warranty 2 Years
