CSS606-1G-2Gi-3S+OUT
Last items in stock
$228.69
Tax included

Mikrotik GPERx6

Cut the cable clutter – extend power and fiber together, anywhere – with a single hybrid cable. At the far end, the GPERx6 splits it all neatly: SFP+ for further long-distance uplinks, PoE-out for powering other switches or access points, and DC outputs for IoT gear or specialized devices.

Key Features

  • 3 × Gigabit Ethernet ports
  • 3 × 10G SFP+
  • 3 × DC outputs for devices that don’t use PoE
  • Rugged IP66-rated enclosure with mounting hardware included
  • Powered by a dedicated 10G switch chip
  • Flexible power input options: DC jack (12–57 V) and PoE-in (42–57 V, 802.3bt standard)
  • Heavy-duty IP66 enclosure

Quantity Unit price You Save
2 $217.26 $22.87
5 $202.39 $131.50
10 $197.82 $308.73
15 $195.53 $497.40
20 $193.24 $708.94


CSS606-1G-2Gi-3S+OUT Mikrotik 3 Gigabit + 3×10G SFP+ Hybrid PoE Outdoor IP66 Switch

The MikroTik GPERx6 is a compact outdoor switch designed for demanding environments. It combines data and power delivery, featuring Gigabit Ethernet ports, 10G SFP+ ports, and PoE-out capabilities for powering devices like IP cameras and wireless access points. Its rugged IP66-rated enclosure and wide operating temperature range ensure reliable performance in harsh conditions.

Built for the toughest deployments

The outdoors can be brutal: blistering heat, freezing cold, wind, rain. The elements attack your gear. The wiring is a nightmare. The GPERx6 solves both problems – a rugged, outdoor-ready switch that cuts cable clutter and keeps deployments simple.

But the real advantage is how it allows you to manage power and data over long distances (1-2 km) even in the trickiest scenarios!

Hybrid cable advantage

With hybrid fiber + copper cables, the GPERx6 becomes a power-and-data lifeline:

  • Fiber strands carry your high-speed uplink.
  • Copper conductors deliver DC power.
  • At the far end, the GPERx6 splits it all:( SFP+ uplinks for data, PoE-out for other switches or access points, DC-out for IoT devices or special hardware.)

Product Specifications

Product Code CSS606-1G-2Gi-3S+OUT
Switch Chip Model 88E6193X
Operating System SwOS
MTBF Approximately 200,000 hours at 25°C
Tested Ambient Temperature -40°C to 70°C
Powering
Number of DC Inputs 2 (PoE-IN, DC jack)
DC Jack Input Voltage 12-57 V
Max Power Consumption 160 W
Max Power Consumption Without Attachments 6 W
PoE In 802.3 bt
Cooling Type Passive
PoE In Input Voltage 42-57 V
PoE-Out
PoE-Out Ports Ether2-Ether3
PoE Out Passive PoE up to 57V
Low Voltage PoE-Out Current Limit 1.2 A
High Voltage PoE-Out Current Limit 0.625 A
Max Total Out (A) 2.4 A
Total Output Power 150
Ethernet
10/100/1000 Ethernet Ports 3
Number of 1G Ethernet Ports with Reverse PoE (PoE-In) 1
Number of 1G Ethernet Ports with PoE-Out 2
Fiber
SFP+ Ports 3
Other
CPU Temperature Monitor Yes
Certification & Approvals
Certification CE, EAC, ROHS
IP Rating 66
CSS606-1G-2Gi-3S+OUT
