IGS-1600T IP30 Industrial 16-Port Switch (-40~75 degrees C, dual 12~48V DC/24V AC)
IGS-1600T IP30 Industrial 16-Port Switch (-40~75 degrees C, dual 12~48V DC/24V AC)
IGS-1600T IP30 Industrial 16-Port Switch (-40~75 degrees C, dual 12~48V DC/24V AC)
IGS-1600T IP30 Industrial 16-Port Switch (-40~75 degrees C, dual 12~48V DC/24V AC)

IGS-1600T IP30 Industrial 16-Port 10/100/1000T Ethernet Switch (-40~75 degrees C, dual 12~48V DC/24V AC)

IGS-1600T
Last items in stock
$410.72
Tax included

IGS-1600T IP30 Industrial 16-Port Gigabit Ethernet Switch (-40~75 degrees C, dual 12~48V DC/24V AC)

PLANET IGS-1600T Industrial high-density 16-port 10/100/1000T Gigabit Ethernet Switch is equipped with a rugged IP30 metal case for stable operation in heavy industrial demanding environments. Thus, the IGS-1600T provides a high level of immunity against electromagnetic interference and heavy electrical surges which are usually found on plant floors or in curbside traffic control cabinets.

Note: Power supply is not included, please select from the checklist below.

Related Products & Accessories



IGS-1600T IP30 Industrial 16-Port Gigabit Ethernet Switch (-40~75 degrees C, dual 12~48V DC/24V AC

Physical Port

  • 16-port 10/100/1000BASE-T RJ45 with auto MDI/MDI-X function


Layer 2 Features

  • Complies with IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX, IEEE 802.3ab 1000BASE-T Ethernet standard
  • Supports auto-negotiation and 10/100/1000Mbps half/full duplex mode
  • Prevents packet loss with back pressure (half-duplex) and IEEE 802.3x pause frame flow control (full-duplex)
  • Complies with IEEE 802.3az Energy Efficient Ethernet (EEE)
  • IEEE 802.1p CoS
  • Supports 8K MAC address
  • Automatic address learning and address aging


Industrial Case and Installation

  • IP30 metal case
  • DIN-rail and wall-mount designs
  • 12 to 48V DC, redundant power with reverse polarity protection
  • 24V AC power input
  • Supports 6000 VDC Ethernet ESD protection
  • -40 to 75 degrees C operating temperature
  • Free fall, shock-proof and vibration-proof for industries

Device Type
Network Switch
Device Features
Industrial
Power Input
AC
DC
Installation Type
DIN-rail
Wall-mount
Ports
16 Ports 10/100/1000TX
Type
Unmanaged
Throughput
23.81Mpps @ 64Bytes
Switch Fabric
32Gbps / non-blocking
Max. Power Consumption
AC Input: 13.99W/47.8BTU (full loading)
DC Input: 8.7W/29.7BTU (full loading)
4711605284882
IGS-1600T
No reviews
