ECB-8610 EnGenius Dual Band Access Point

ECB-8610 - 400mW 802.11a/b/g Wireless AP/Client/Bridge

The Wireless High Power and High Gain Multi-Client Bridge/Access Point/ WDS (wireless distribution system) operates seamlessly in the dual band 2.4/5 GHz frequency spectrum supporting the 802.11b (2.4GHz, 11Mbps) and the newer, faster 802.11g (2.4GHz, 54Mbps) wireless standards. It's the best way to add wireless capability to your existing wired network, or to add bandwidth to your wireless installation.

To protect your wireless connectivity, it can encrypt all wireless transmissions through 64/128-bit WEP data encryption and also supports WPA. The MAC address filter lets you select exactly which stations should have access to your network. With the Wireless Multi-Client Bridge/Access Point/WDS, you'll experience the best wireless connectivity available today.

Specifications

Data Rates
1, 1, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54 Mbps

Standards
IEEE802.11a/b/g, IEEE802.3, IEEE802.3u, IEEE802.3af, IEEE802.1f, IEEE802.1x

Compatibility
IEEE 802.11g/ IEEE 802.11b

Power Requirements
Power Supply: 90 to 240 VDC ± 10% (depends on different countries)
Device: 12 V/ 1A

Status LEDs
LAN: Link, WLAN: Link, Power: on/off

Regulation Certifications
FCC Part 15/UL, ETSI 300/328/CE

RF Information
Frequency Band
802.11a: 5.15~5.25GHz, 5.25~5.35GHz, 5.47~5.725GHz, 5.725~5.825GHz
802.11b/g: U.S., Europe and Japan product covering 2.4 to 2.484 GHz, programmable for different country regulations

Media Access Protocol
Carrier Sense Multiple Access with Collision Avoidance (CSMA/CA)

Modulation Technology
Orthogonal Frequency Division Multiplexing (OFDM)
DBPSK @ 1Mbps
DQPSK @2Mbps
CCK @ 5.5 & 11Mbps
BPSK @ 6 and 9 Mbps
QPSK @ 12 and 18 Mbps
16-QAM @ 24 and 36 Mbps
64-QAM @ 48 and 54 Mbps

Operating Channels
11 for North America, 14 for Japan, 13 for Europe,

Receive Sensitivity (Typical)
5.15~5.85G(IEEE802.11a)
6Mbps@ -88dBm;
54Mbps@ -70dBm
2.412~2.472G(IEEE802.11g)
6Mbps@ -91dBm;
54Mbps@ -74dBm
2.412~2.472G(IEEE802.11b)
11Mbps@ -90dBm
1Mbps@ -95dBm
Available transmit power

(Typical)
5.15~5.24 GHz(IEEE802.11a)
17dBm @6 ~ 24Mbps
17dBm @36Mbps
16dBm @48Mbps
15dBm @54Mbps

5.26~5.35GHz(IEEE802.11a)
20dBm @6 ~ 24Mbps
18dBm @36Mbps
16dBm @48Mbps
15dBm @54Mbps

5.745~5.85GHz (IEEE802.11a)
18dBm @6 ~ 24Mbps
16dBm @36Mbps
14dBm @48Mbps
13dBm @54Mbps

2.412~2.472G(IEEE802.11g)
26dBm @6 ~ 24Mbps
23dBm @36Mbps
22dBm @48Mbps
21dBm @54Mbps

2.412~2.472G(IEEE802.11b)
up to 26 dBm. @1, 1, 5.5 and 11Mbps
RF Connector
TNC Type (Female Reverse)

Networking

Topology
Ad-Hoc, Infrastructure

Interface
One 10/100Mbps RJ-45 LAN Port

Operation Mode
Point-to-Point/ Point-to-Multipoint Bridge/ AP/ Client Bridge/ WDS

Security

l IEEE802.1x Supplicant (EAP-MD5/TLS/TTLS, PEAP) support in Client Bridge Mode
l WPA /WPA2/ Pre Share KEY (PSK) with TKIP/AES
l MAC address filtering (AP only)
l Hide SSID in beacons

IP Auto-configuration
DHCP client/server
Management

Configuration
Web-based configuration (HTTP)
Telnet Configuration
SNMP V1,

Firmware Upgrade
Upgrade firmware via web-browser

Environmental

Temperature Range
Operating: 0°C to 45°C (32°F to 113°F)
Storage: -40°Cto 70°C (-40°F to 158°F)

Humidity (non-condensing)
5%~95% Typical

Package Contents
One Multi-Client/AP/WDS
One Power Adapter
One CAT5 UTP Cable
One Quick Start Guide
One CD-ROM with User’s Manual
