Ubiquiti airMAX Titanium 5GHz 15-17dBi 2x2 Adjustable Beamwidth Sector Antenna
AM-M-V5G-TI 5.45-5.85GHZ Mid-Gain Sector Ant 60-120deg
Building upon our market-leading Rocket™ series, the Rocket™M Titanium features enhanced radio perfomance and superior durability. Thoughtfully engineered with Gigabit Ethernet, RocketM Titanium models achieve massive throughput increase along with unleashed speed. Its Carrier-Class capabilities link distances up to 50+ km and provide breakthrough speed of up to 150+ Mbps real TCPI/IP throug
AM-M-V5G-TI 5.45-5.85GHZ Mid-Gain Sector Ant 60-120deg
Features of AM-M-V5G-Ti:
Revolutionary, Cost/Performance Breakthrough Carrier Class, 5GHz AirMax 2x2 MIMO Basestation Sector Antennas.
Adjustable 60-120 Degree 5 Ghz MIMO 19-21 dbi Sector cable
Powerful airMAX™ BaseStation Platform
Building upon our market-leading Rocket™ series, the Rocket™M Titanium features enhanced radio perfomance and superior durability. Thoughtfully engineered with Gigabit Ethernet, RocketM Titanium models achieve massive throughput increase along with unleashed speed. Its Carrier-Class capabilities link distances up to 50+ km and provide breakthrough speed of up to 150+ Mbps real TCPI/IP throughput.
The RocketM Titanium enclosure was specifically designed to improve performance in harsh RF environments and in extreme weather conditions. Enclosed in aircraft-grade aluminum, the RocketM Titanium is a rugged, high-power, linear 2x2 MIMO radio.
Rocket devices may be deployed in PtP bridging or PtMP airMAX BaseStation applications. They can be paired with your choice of airMAX BaseStation™ Sector or RocketDish™ antennas. This versatility gives network architects unparalleled flexibility and convenience.
airMAX Technology
Unlike standard WiFi protocol, Ubiquiti’s Time Division Multiple Access (TDMA) airMAX protocol allows each client to send and receive data using pre-designated time slots scheduled by an intelligent AP controller. This “time slot” method eliminates hidden node collisions and maximizes airtime efficiency. It significantly improves performance in throughput, reduces latency, and increases scalability compared to all other outdoor systems in its class.
Intelligent QoS Priority is given to voice or video for seamless streaming.
Scalability High capacity and scalability.
Long Distance Capable of high-speed links up to 50+ km.
Latency Multiple features dramatically reduce noise.
GPS Synchronization*
Specifications of AM-M-V5G-Ti:
- Dimensions 721 x 149.1 x 75.7 mm
- Weight 3.72 kg (with Brackets)
- Frequency Range 5.45 - 5.85 GHz
- Beamwidth Angles 60˚/ 90˚/ 120˚
- Gain (Beamwidth Dependent) 21 dBi @ 60˚
- 20 dBi @ 90˚
- 19 dBi @ 120˚
- Electrical Downtilt 2˚
- Polarization Dual Linear
- Cross-Pol Isolation 20 dB Min.
- F/B Ratio 30 dB
- Max. VSWR 1.5:1
- RF Connectors 2 SMA Connectors (Weatherproof )
- Compatible Radios RocketM5 (not included): RocketM5 GPS, RocketM5 Titanium
- Mounting Pole Mount (Kit Included)
- ETSI Specification EN 302 326 DN2
- Wind Survivability 160 mph
- Wind Loading 37 lbs @ 120 mph
- Antenna Gain (dBi)
- 17
- Device Type
- Antenna
- Antenna Type
- Dual Polarity
Sector - MIMO
- 2x2
- Wireless System
- 5GHz
